EMC Celerra NX4

12
For more information, refer to Celerra Tools on http://Powerlink.EMC.com
Cabling EMC Celerra NX4 system
Cable the Celerra NX4 dual blade Fibre Channel ports.
Control Station
(CS)
Standby power
supply (SPS)
SPS A
Blade 3
SP B
Blade 2
CNS-001431
Blade enclosure
SP A
Disk processor
enclosure (DPE)
0 Fibre
3 AUX
2 AUX 1 Fibre
BE1Blade 2
Blade 2 BE0
BE1Blade 3
Blade 3 BE0
SP A 2 AUX
SP B 2 AUX
SP A 3 AUX
SP B 3 AUX
1
3
4
2
BE0Blade 2
BE1
Blade 3
SP A 2 AUX
SP B 3 AUX
SP A 3 AUX
SP B 2 AUX
0 Fibre
3 AUX
2 AUX 1 Fibre
BE1Blade 2
BE0
Blade 3
BE 1
BE 0
BE 1
BE 0
43
1
2
SPS B
Note: The blades in your system may have four port Ethernet copper or two port 10 GbE optical and
two port copper.
