EMC Celerra NX4 - Private LAN Cabling; Private LAN Port Connections

14
For more information, refer to Celerra Tools on http://Powerlink.EMC.com
Cabling EMC Celerra NX4 system
Cable the Celerra NX4 dual blade private local area network (LAN) ports.
SPS B
CS A
Blade 2
Blade 2
SP A
SP B
Blade 3
CS
B
Blade 3
1
2
4
3
Disk processor
enclosure (DPE)
Control Station
(CS)
Standby power
supply (SPS)
Blade enclosure
SPS A
SP B
Blade 2
SP A
SP B
CS A
Blade 2
SP A
Blade 2
4
1
3
2
CNS-001432
Blade 3
CS B
Blade 3
Note: The blades in your system may have four port Ethernet copper or two port 10 GbE optical and
two port copper.
