6
Step 2
Set Up Fibre Channel Loops (continued)
The illustration below shows an example storage-system configuration with
two redundant DAE2 loops segregated above and below the SPE.
EMC2351
SPS B
SP B
SP A
EA4/Loop 0
EA4/Loop 1
EA3/Loop 0
EA3/Loop 1
EA2/Loop 0
EA2/Loop 1
EA1/Loop 0
EA1/Loop 1
EA0/Loop 0
EA0/Loop 1
SPS A
PRI
EXP
LCC ALCC B
Loop 1
Loop 0
Loop 1
Loop 0
