VNX5700 Block and File product description
VNX5700 Hardware Information Guide 15
Note: The previously mentioned dimensions are approximate and do not include the
cabinet enclosure and any DAEs.
For physical, environmental, and power details, refer to
VNX5700 Storage System
Technical Specifications and Operating Limits
document.
Configured for AC-input power, the Block and File VNX5700 platform includes the
following hardware features:
◆ One dual 2U standby power supply (SPS)
7
◆ One SPE:
• On the front of the SPE, two power supply/cooling (fan) modules and one CPU
module per SP are supported.
– A CPU module with an Intel Xeon 4-core 2.4-GHz processor with six Double Data
Rate Three (DDR3) synchronous dynamic RAM (SDRAM) slots supporting 2, 4,
or 8-GB SDRAM
• On the rear of the SPE, each storage processor (Figure 3 on page 9) consists of:
– One management module
– Five PCI Gen 2 x4 I/O module slots supporting a combination of the following
five UltraFlex
™
I/O modules:
Four-port 6-Gb/s SAS (slot 0 only)
Two-port 10-Gb/s optical or active Twinax
8
(iSCSI protocol)
Two-port 10-Gb/s optical or active Twinax Fibre Channel over Ethernet (FCoE)
Table 2 VNX5700 hardware feature quick reference
Minimum
form
factor
Maximum
# of drives
Drive
types
File Block
Config.
I/O slots
per Data
Mover
Data
Movers
System
memory
per Data
Mover Protocols
Config.
I/O
slots
per SP SPs
System
memory
per SP Protocols
9-10U
1
500 3.5 in.
SAS,
NL-SAS,
Flash,
and 2.5
in. 10 K
SAS
4 2, 3, or
4
12 GB NFS,
CIFS,
MPFS
2
and
pNFS
3
5 2 18 GB FC, iSCSI,
and FCoE
1. Does not include DAEs.
2. MPFS = Multi-Path File System
3. pNFS = parallel-NFS
7. A dual 2U SPS is used when the 4U DAE with Flash drives is used in a Vault drive configuration in
na 40U Dense rack. Otherwise, the dual 1U SPS is used with the 3U DAE as the Vault drive.
8. The two-port 10-Gb/s and FCoE I/O modules can also use active twinaxial (Twinax) cables. Twinax
is a type of cable similar to coax, but with two inner conductors instead of one. These cables will
be supplied in lieu of the SFP+ when so ordered.
