13. Main Board
Power supply
FUSE
Solenoid
Power supply
FUSE
Solenoid
+ Level
Level probe switch
input
(- Level)
Power supply
FUSE
Solenoid
+ Level
External Pulse or
Water meter
cable input
+ -
(- Level)
Power supply
FUSE
Solenoid
+ Level
Water meter
cable input
+ -
(- Level)
230/115 VAC
230/115 VAC
230/115 VAC
230/115 VAC
“CO” Power
Circuit Board
“CL Power
Circuit Board
“IS/IC” Power
Circuit Board
“PV” Power
Circuit Board
