B Appendix. Construction Materials and Technical info
POWER SUPPLY FREQ. FUSE
230 VAC (180-270 VAC) 50/60 Hz 1,25 A
115 VAC (90-135 VAC) 50/60 Hz 1,6 A
24 VAC (20-32 VAC) 50/60 Hz 6,3 A
12 VDC (10-16 VDC) 5 A
Injection/min 0 ÷ 120 (except for 0260:130 injection/min)
Max suction height 1,5 m
Environment temperature: 0 ÷ 45°C (32 ÷ 113°F)
Chemical temperature: 0 ÷ 50°C (32 ÷ 122°F)
Transportation and storage temperature: -10 ÷ 50°C (14 ÷ 122°F)
Altitude 2000 m
Installation Class: II
Pollution level: 2
Audible noise: AMS/AMSA: 57.4 db(A);
AMS/AMSA silenced: 54.4 db(A);
AMS/AMSA ultra silenced: 53.4 db(A);
AMS AC: 78.3 db(A)
Protection degree: AMS / AMSA / AMS AC: IP 65
For AMS AC mod. (AMS AC CO e AMS AC CL):
Compressed air suction 30 l/h (suction air)
Suction air pressure 7 bar
Compressed air pumps work only with compressed air without lubrificant and/or condensed water. Air supply pressure range
must be from 6 to 10 bar.
