Appendix - Lock / Unlock from the wall mounting rack
To lock controller to the wall gently insert (1) upper case to the wall mounting rack and move it (2) down until it locks to
the lower part of the wall mounting rack.
To unlock controller from the wall pull (3) the handle from the wall mounting rack and raise up (4) the controller.
