Emerald Spa Lite Leader - Power Pack

One-Pump System
Below is a general description for the one pump system of the Lite Leader,
SS-1D, and SS-3D used in your Emerald spa.
1. control panel - (SS-3D shown) 10. connector plumbing elbow
2. temperature sensor 11. heater
3. ozone generator (optional) 12. control outputs
4. light 13. power pack
5. 2-speed circulation/jets pump 14. water outlet T-valve
6. water inlet T-valve 15. water outlet line to spa
7. water inlet line from spa 16. ozone tee
8. air line from blower to spa 17. grounding wire
(not on Base Models)
9. air blower
(not on Base Models)
Power Pack
This diagram represents a generic one pump
system. It is not intended to represent any
specific model.
Features and Controls
15
