10.9 Menu 8: Digital inputs and outputs
Table 10-14 Menu 8 parameters: single line descriptions
Parameter Range Default Setting Update Rate
8.01 Terminal B3 digital input/output state OFF(0) or On(1)
2 ms
8.02 Terminal B4 digital input state OFF(0) or On(1)
2 ms
8.03 Terminal B5 digital input state OFF(0) or On(1)
2 ms
8.04 Terminal B6 digital input state OFF(0) or On(1)
2 ms
8.05 Terminal B7 digital input state OFF(0) or On(1)
2 ms
8.06 Not used
8.07 Status relay state (Terminals T5 & T6) OFF(0) or On(1) 2 ms
8.08 Not used
8.09 Not used
8.10 Not used
8.11 Terminal B3 digital input/output invert OFF(0) or On(1) OFF(0) 2 ms
8.12 Terminal B4 digital input invert OFF(0) or On(1) OFF(0) 2 ms
8.13 Terminal B5 digital input invert OFF(0) or On(1) OFF(0) 2 ms
8.14 Terminal B6 digital input invert OFF(0) or On(1) OFF(0) 2 ms
8.15 Terminal B7 digital input invert OFF(0) or On(1) On(1) 2 ms
8.16 Not used
8.17 Status relay invert OFF(0) or On(1) OFF(0) 2 ms
8.18 Not used
8.19 Not used
8.20 Digital I/O read word {90} 0 to 95 B
8.21
Terminal B3 digital input destination/output
source
Pr 0.00 to 21.51 Pr 10.03 Drive reset
8.22 Terminal B4 digital input destination Pr 0.00 to 21.51 Pr 6.29 Drive reset
8.23 Terminal B5 digital input destination Pr 0.00 to 21.51 Pr 6.30 Drive reset
8.24 Terminal B6 digital input destination Pr 0.00 to 21.51 Pr 6.32 Drive reset
8.25 Terminal B7 digital input destination Pr 0.00 to 21.51 Pr 1.41 Drive reset
8.26 Not used
8.27 Status relay source Pr 0.00 to 21.51 Pr 10.01 Drive reset
8.28 Not used
8.29 Not used
8.30 Not used
8.31 Terminal B3 mode select in(0), out(1), Fr(2), PuLS(3) out(1) B
8.32 Not used
8.33 Not used
8.34 Not used
8.35 Terminal B7 mode select {34} dig(0), th(1), Fr(2), Fr.hr(3) dig(0) B
8.36 Not used
8.37 Not used
8.38 Not used
8.39 Not used
8.40 Not used
8.41 Digital output control (Terminal B3) {35}
n=0(0), At.SP(1), Lo.SP(2),
hEAL(3), Act(4), ALAr(5),
I.Lt(6), At.Ld(7), USEr(8)
n=0(0) Edit mode exit
