Commander SK Advanced User Guide 141
Issue Number: 9 www.controltechniques.com
Table 10-23 Parameter changes when drive configuration is changed
1. If last default setting was Eur, then Pr 6.04 is 0. If last default setting was USA, then Pr 6.04 is 4 except in HVAC mode where Pr 6.04 is 0.
2. If last default setting was Eur, then Pr 8.22 is 6.29. If last default was USA, then Pr 8.22 is 6.39 except in PAd or HVAC mode where Pr 8.22 is
6.29.
Parameter
number
Description
Drive Configuration
AI.AV AV.Pr AI.Pr Pr PAd E.Pot tor Pid HVAC
71 Configurable parameter 1 set-up Pr 9.23 Pr 14.10
72 Configurable parameter 2 set-up Pr 9.22 Pr 14.11
73 Configurable parameter 3 set-up Pr 9.21 Pr 14.06
74 Configurable parameter 4 set-up Pr 14.13
75 Configurable parameter 5 set-up Pr 14.14
76 Configurable parameter 6 set-up Pr 14.01
77 Configurable parameter 7 set-up
78 Configurable parameter 8 set-up
79 Configurable parameter 9 set-up
80 Configurable parameter 10 set-up
1.14 Reference select 011343020
6.04 Start/stop logic Note 1 Note 1 Note 1 Note 1 Note 1 Note 1 Note 1 Note 1 0
7.06 Analog input 1 mode 4 6 4 666444
7.11 Analog input 2 mode 0 1 1 101000
7.14 Analog input 2 destination Pr 1.37 Pr 1.46 Pr 1.46 Pr 1.46 Pr 1.37 Pr 9.27 Pr 4.08 0Pr 1.37
8.15 Terminal B7 digital input invert 1 0 0 010001
8.22 Terminal B4 digital input destination Note 2 Note 2 Note 2 Note 2 Pr 6.29 Note 2 Note 2 Note 2 Pr 6.29
8.25 Terminal B7 digital input destination Pr 1.41 Pr 1.45 Pr 1.45 Pr
1.45 Pr 1.41 Pr 9.26 Pr 4.11 Pr 14.08 Pr 1.43
9.25 Motorized pot destination 0 0 0 0 0 Pr 1.21 000
14.03 PID reference source 0000000Pr 7.02 0
14.04 PID feedback source 0 0 0 0000Pr 7.01 0
14.16 PID destination 0000000Pr 1.37 0
Pr 11.27 Configuration Description
0 AI.AV Voltage and current input
1 AV.Pr Voltage input and 3 preset speeds
2 AI.Pr Current input and 3 preset speeds
3 Pr 4 preset speeds
4 PAd Keypad control
5 E.Pot Electronic motorized potentiometer control
6 tor Torque control operation
7 Pid PID control
8 HVAC Fan and pump control
