Control
CC
L1
L2
L2L1
120v
240v
M
2
L
A
Injection
Solenoid
Temp.
Sensor
Injector Control
Switch
L
M
A
S
Demand
Cooling Module
CoreSense
Module Terminal
Strip
* 120v or
240v
NOTE: The CoreSense module is dual rated for 120v / 240v.
The Demand Cooling module must be matched to the line voltage.
Current
Sensor
Current Sensor Connector
Contactor
Figure 5E
Coresense Protection with Copeland Demand Cooling
