Emerson Alco Controls TIH Series

TIH
Emerson Climate Technologies GmbH www.emersonclimate.eu Date: 19.02.2020
Am Borsigturm 31 I 13507 Berlin I Germany TIH_OI_EN_DE_FR_ES_IT_RU_0220_R05_865925.docx
Fig./ / Pис. 1
Fig./ Pис. 2:
Fig./ Pис. 4
< 7/8” (28 mm/мм) ≥ 7/8“ (28 mm/мм)
Fig. / Pис. 5
Fig. / Pис. 8
Dimensions / Abmessungen / Dimensions / Dimensiones / Dimensioni / Размеры (mm/мм)
Fig. / Pис. 6
Type
ODF (mm/мм)/ (inch/дюйм)
(mm/мм)
A
B
C
D
E
F
G
H
J
K
L
M
TIH-...2
6 / 1/4" 10 / 3/8" internal - -
70.7 8.4 8.4
10.3
87.5 73 45
TIH-..3
TIH-..2
6 / 1/4" 10 / 3/8" 6 / 1/4" 43.5 8.4
TIH-..3
TIH-..4
10 / 3/8"
12 / 1/2"
internal
-
-
68.7 10.4 8.4
TIH-..4
10 / 3/8" 12 / 1/2" 6 / 1/4"
43.5 8.4
TIH-..5
TIH-..6
TIH-..7
12 / 1/2" 16 / 5/8" 6 / 1/4" 64 13.1 10.4
TIH-..8
TIH-..9
TIH-..A
Charge
(mm/мм)
N
R
Ø S
T
M0/M2, N0/N2, B0/B2, C0/C2
10
5
15.9
53
M1/M3, N1/N3, Z1/Z3, C1/C3
10
5
12.6
53
