ANDERSON GREENWOOD SERIES 9300 PILOT OPERATED SAFETY RELIEF VALVES

InstallatIon and MaIntenance InstructIons

8.1 - 91 PILOT REPAIR KIT (04.4744.XXX)

Pilot type Pressure Kit type Material Pressure

91 Pilot 15 - 50 psig Soft goods PTFE/Stainless 003

NOTES

Kalrez

is a registered trademark of DuPont Dow Elastomers

8.2 - 93 PILOT REPAIR KIT (06.0235.XXX)

Pilot Series Pressure Kit type Material Pressure Vacuum

93 Pilot 4”WC - 14.9 psig Soft goods NBR 133 152

93 Pilot 4”WC - 14.9 psig Soft goods FKM 134 153

93 Pilot 4”WC - 14.9 psig Soft goods EPR 135 154

93 Pilot 4”WC - 14.9 psig Soft goods NBR

[1]

136 155

93 Pilot 4”WC - 14.9 psig Soft goods FKM

[1]

137 156

93 Pilot 4”WC - 14.9 psig Soft goods EPR

[1]

138 157

93 Pilot 4”WC - 14.9 psig Bolt SST 287 287

93 Pilot marine 4”WC - 14.9 psig Bolt SST 702 702

93 Pilot 15 - 50 psig* Soft goods NBR 141 -

93 Pilot 15 - 50 psig* Soft goods FKM 142 -

93 Pilot 15 - 50 psig* Soft goods EPR 143 -

93 Pilot 15 - 50 psig* Bolt SST 416 -

1. PTFE diaphragm

* (3 - 50 psig marine)

8.3 - 93T PILOT REPAIR KIT (06.0235.XXX)

Pilot Series Pressure Kit type Material Pressure Vacuum

93T Pilot 4”WC - 15 psig Soft goods PTFE 139 158

93T Pilot 4”WC - 15 psig Bolt SST 288 288

93T Pilot marine 4”WC - 15 psig Bolt SST 701 701

8.4 - 400A/B PILOT REPAIR KIT (06.0235.XXX)

Pilot Series Pressure Kit type Material Pressure Vacuum

400A/B Pilot 4”WC - 10”WC Soft goods NBR

[1]

127 149

400A/B Pilot 4”WC - 10”WC Soft goods FKM

[1]

128 150

400A/B Pilot 4”WC - 10”WC Soft goods EPR

[1]

129 151

400A/B Pilot 4”WC - 10”WC Soft goods Kalrez

[1]

455 456

400A/B Pilot >10” WC - 15 psig Soft goods NBR

[1]

558 562

400A/B Pilot >10” WC - 15 psig Soft goods FKM

[1]

559 563

400A/B Pilot >10” WC - 15 psig Soft goods EPR

[1]

560 564

400A/B Pilot >10” WC - 15 psig Soft goods Kalrez

[1]

561 565

400A/B Pilot 4” WC - 15 psig Bolt SST 409 409

1. PTFE diaphragm

8.5 - 400A PILOT REPAIR KIT (06.0235.000)

Pilot Series Pressure Kit type Material Pressure Vacuum

400A Pilot 15 - 50 psig Soft goods NBR

[1]

458 -

400A Pilot 15 - 50 psig Soft goods FKM

[1]

459 -

400A Pilot 15 - 50 psig Soft goods EPR

[1]

460 -

400A Pilot 15 - 50 psig Soft goods Kalrez

[1]

461 -

400A Pilot 15 - 50 psig Bolt SST 462 -

1. PTFE diaphragm

8 PILOT SPARE PARTS AND REPAIR KITS
