Installation
EN Only
EN
The I/O connector is a 10-pin removable terminal block. It is recommended that #18 to 24
AWG stranded wire be used.
Epsilon Only
The I/O connector is a 26-pin male connector on the front of the drive. Control Techniques
offers a low profile interface plug (STI-EIO) and cable (EIO-xxx) for connections.
Figure 75: EN I/O Connector to Command Connector Internal Connections
