Epsilon Eb and EN Drives Reference Manual
NTE-207 and 212 Brake Motors; Metric Face
159,
Note
Mounting ears have clearance for 10mm across flats hex nut or 13mm O.D. washer.
NTM-207, 212 -CBNS, TBNS and LBNS Mounting Dimensions
mm (inches)
A B C
D
Max
E F G
I
Max
J
Max
K
Min
L
Min
M
Min
207-CBNS
176.40
(6.945)
65.18
(2.566)
7.49
(0.295)
60.012
(2.363)
2.54
(0.10)
5.80
(0.228)
75.00
(2.953)
23.51
(0.926)
10.999
(0.433)
13.0
(0.512)
3.97
(0.156)
2.0
(0.079)
207-
TBNS/
LBNS
159.44
(6.277)
65.18
(2.566)
7.49
(0.295)
60.012
(2.363)
2.54
(0.10)
5.80
(0.228)
75.00
(2.953)
23.51
(0.926)
10.999
(0.433)
13.0
(0.512)
3.97
(0.156)
2.0
(0.079)
212-CBNS
201.80
(7.945)
65.18
(2.566)
7.49
(0.295)
60.012
(2.363)
2.54
(0.10)
5.8
(0.228)
75.00
(2.953)
23.51
(0.926)
10.999
(0.433)
13.0
(0.512)
3.97
(0.156)
2.0
(0.079)
212-
TBNS/
LBNS
184.84
(7.277)
65.18
(2.566)
7.49
(0.295)
60.012
(2.363)
2.54
(0.10)
5.8
(0.228)
75.00
(2.953)
23.51
(0.926)
10.999
(0.433)
13.0
(0.512)
3.97
(0.156)
2.0
(0.079)
1.98 [50.39]
MAX
BRAKE CONN: PT02E-8-3P
MATING CONN: PT06E-8-3S (-CBNS)
ENCODER CONN: PT02E-16-23P
MATING CONN: PT06E-16-23S (-CBNS)
MOTOR CONN: PT02E-16-8P
MATING CONN: PT06E-16-8S (-CBNS)
A
J
FLYING LEAD LENGTH:
39.37±2.00 [1000±50.8]
(-LBNS and -TBNS)
J
ENCODER CONN: PT02E-16-23P
MATING CONN: PT06E-16-23S
(-TBNS)
BRAKE CONN: PT02E-8-3P
MATING CONN: PT06E-8-3S
(-TBNS)
MOTOR CONN: PT02E-16-8P
MATING CONN: PT06E-16-8S
(-TBNS)
