Emerson Control Techniques Epsilon Eb Series User Manual

195
Specifications
Cooling Method
EN-204, EN-208: Natural Convection
EN-214: Integral thermally controlled fan
(60°)
Eb-202, Eb-203, Eb-205: Natural Convection
Environmental
Ambient temperature range for rated output: 32° F to 104° F (O° C to 40° C)
Maximum ambient operating temperature: 104° F to 122° F (40° C to 50° C) with power
derating of 3%/°C
Rated altitude: 3,280 feet (1000 m)
Vibration: 10 - 2000 Hz at 2g
Humidity requirement: 10 - 95% non-condensing
Storage temperature: -13 °F to 167 °F (-25 °C to 75 °C)
Derating
Temperature:
Operation in ambient temperature over 50° C (122° F) not recommended.
Drive output power must be derated by 3 %/°C between 104° F to 122° F (40° C to 50° C)
Single phase operation:
EN-214 drive output power rating is reduced by 20%
Derating altitude: Above 3,280.8 ft (1000 m) reduce output by 1% per 328.08 ft (100 m)
Standards and Agency
Approvals
UL Listed
Canadian UL Listed
CE Mark: Low voltage directive; EMC
directive
UL listed
Canadian UL listed
CE Mark: Low voltage directive; EMC
directive
Accessory Specifications
ALP-130: Input 115/230 VAC; Output 140
VDC, 30 W
ALP-430: Input 115/230 VAC; Output 140
VDC, (4)x20 W
Amplifier Weights
EN-204 6.4 lb (2.9 kg)
EN-208
7.7 lb (3.5 kg)
EN-214 8.9 lb (4.0 kg)
Eb-202 3.3 lb (1.5 kg)
Eb-203 3.3 lb (1.5 kg)
Eb-205 3.7 lb (1.7 kg)
EN Epsilon Series
