Figure 3
Digital Scroll Cross Sectional View
ZPD103KC, ZPD120KC, ZPD137-182KC and ZRD94-125KC
Removable External
Solenoid and Coil
Floating Seal Cavity
Seal Cavity Vent
90 Frame Digital Scroll
