8 AGL_HP_VS_YHV2P_E_Rev0
Legend
YHV0382P-4X9 No drive limitation
(rpm)
YHV0382P-4X9 + ED3018B
(rpm)
1200
1200
1800
1800
2400-5400
2400-4500
2400-7200
Linear interpolation
Linear interpolation
2400-5400
Linear interpolation
2400-7200
Figure 6: Application envelope and legend for YHV0382P-4E9 using R452B and R454B
Legend
YHV0382P-9X9 No drive limitation
(rpm)
YHV0382P-9X9 + ED3020A
(rpm)
1200-5400
1200-3600
1800-5400
1800-3600
2400-5400
2400-3600
2400-7200
2400-4500
Not shown
2400-7200
Figure 7: Application envelope and legend for YHV0382P-9X9 using R452B and R454B
