Emerson Copeland Scroll ZR KA Series Application Engineering Bulletin

AE4-1312 R2
© 2010 Emerson Climate Technologies
Printed in the U.S.A.
17
Model Frame Size*
Charge Limit 120% x Limit **
Pounds kg Pounds kg
ZR16-ZR29KC 53 6 2.7 7.2 3.24
ZR16-ZR24K4 53 6 2.7 7.2 3.24
ZR26-ZR48KC 63 8 3.6 9.6 4.32
ZR18-ZR48K3 63 8 3.6 9.6 4.32
ZR54-ZR81KC 70 10 4.5 12.0 5.40
ZR54-ZR61K3 70 10 4.5 12.0 5.40
ZR16-ZR34KA 53 8 3.6 9.6 4.32
ZR38-ZR54KA 63 10 4.5 12.0 5.40
TANDEM 63 10 4.5 12.0 5.40
TANDEM 70 12 5.5 14.4 6.60
Table 5
Compressor Refrigerant Charge Limits
*Approximate Shell Diameter (e.g. 63 = 6.5 Inches)
** Charge Allowance for system
Table 6
Crankcase Heaters
Copeland
®
Model
Frame
Size
Emerson Part # Volts Watts Tutco Part # Leads
ZR16KC/4 - ZR29KC/4
ZR16KA - ZR34KA
53 018-0052-00 240 40 02-6319-00 21”
53 018-0052-01 120 40 02-6319-02 21”
ZR18K3 - ZR48K3
ZR26KC - ZR48KC
ZR38KA - ZR54KA
63 018-0041-00 240 40 02-6307-00 21”
63 018-0041-01 120 40 02-6307-02 21”
63 018-0041-02 480 40 02-6307-03 21”
63 018-0041-03 575 40 02-6307-06 21”
63 018-0041-04 240 40 02-6311-00 48”
63 018-0041-05 480 40 02-6311-03 48”
63 018-0041-06 240 40 02-6313-00 32”
ZR54K3 - ZR61K3
ZR54K3 - ZR81KC
All 018-0057-XX
Heaters t both 63 and
70 frame* shells
70 018-0057-00 240 70 02-6332-00 21”
70 018-0057-01 480 70 02-6332-03 21”
70 018-0057-02 575 70 02-6332-06 21”
63 & 70
018-0057-03 240 70 02-6334-00 32”
018-0057-04 240 70 02-6335-00 48”
018-0057-05 480 70 02-6335-03 48”
018-0057-06 575 70 02-6335-06 48”
018-0057-07 120 70 02-6335-02 48”
018-0057-08 400 70 02-6335-12 48”
018-0057-09 277 70 02-6332-04 21”
*Approximate Shell Diameter (e.g. 70 = 7.3 Inches)
