Emerson Copeland Scroll ZR KC Series User Manual

26
© 2016 Emerson Climate Technologies, Inc.
AE4-1303 R15
Table 4 - Compressor Accessories & Service Parts
Part
Category
Part Description ZR84-144KC ZR160-190KC ZP90-137KC ZP154-182KC
Mounting Spacer-Mounting Kit 527-0116-00 527-0186-00 527-0116-00 527-0186-00
Crankcase
Heater
Crankcase Heater, 120V 018-0091-21 018-0091-21 018-0091-21 018-0091-21
Crankcase Heater, 240V 018-0091-22 018-0091-22 018-0091-22 018-0091-22
Crankcase Heater, 480V 018-0091-23 018-0091-23 018-0091-23 018-0091-23
Crankcase Heater, 575V 018-0091-24 018-0091-24 018-0091-24 018-0091-24
Crankcase Heater Junction Box 998-7029-00 998-7029-00 998-7029-00 998-7029-00
Oil
Oil Sight-Glass Kit 998-0010-00 998-0010-00 998-0010-00 998-0010-00
Oil Sight-Glass Rotalock O-ring 020-0028-05 020-0028-05 020-0028-05 020-0028-05
Blank Cap To Cover Sight-Glass 005-1514-00 005-1514-00 005-1514-00 005-1514-00
POE Oil (1 Gallon) 998-E022-01 998-E022-01 998-E022-01 998-E022-01
Oil Access Fitting 510-0715-00 510-0715-00 510-0715-00 510-0715-00
Electrical
Terminal Box & Cover Assembly
1
Terminal Block 021-0227-03
2
021-0100-00
3
021-0227-03
4
021-0227-03
2
021-0100-00
3
021-0227-03
4
Ground Screw (10-32, self tapping) 100-0605-01 100-0605-01
Terminal Block Screw (10-32 x .5" Long) 100-0550-01 100-0550-01 100-0550-01 100-0550-01
Molded Plug (TF* Electricals Only) 529-0099-00 529-0099-00
Protection
Kriwan Module 120/240V not required
replace with
CoreSense
not required
replace with
CoreSense
Kriwan Module 24 V not required not required
Kriwan Diagnose Module 120/240V not required 971-0641-00 not required 971-0641-00
Kriwan Diagnose Module 24 V not required 971-0641-01 not required 971-0641-01
CoreSense Module Kit 120/240V not required 971-0064-05 not required 971-0064-05
CoreSense Module Kit 24V not required 971-0065-04 not required 971-0065-04
Commercial Comfort Alert 543-0038-02 543-0038-02
Discharge Line Thermostat 998-0071-02 998-0071-02 998-0071-02 998-0071-02
Suction &
Discharge
Discharge 1/4" Schrader Fitting 510-0370-00 510-0370-00 510-0370-00 510-0370-00
Discharge Rotalock O-Ring Seal 020-0028-02 020-0028-02 020-0028-02 020-0028-02
Suction Rotalock O-Ring Seal 020-0028-03 020-0028-03 020-0028-03 020-0028-03
Rotalock Service Valve, Suction 1-3/8" 998-0510-46 998-0510-46 998-0510-46 998-0510-46
Rotalock Service Valve, Discharge 7/8" 998-0510-90 998-0510-90 998-0510-90 998-0510-90
Discharge Rotalock Adapter to 7/8"
Sweat
998-0034-08 998-0034-08 998-0034-08 998-0034-08
Suction Rotalock Adapter to 1-3/8" Sweat 998-0034-13 998-0034-13 998-0034-13 998-0034-13
1
Terminal boxes are rarely replaced; please contact Application Engineering if replacement part numbers
are required
2
All Voltages
3
200/230 Volts Only
4
380, 460, 575 Volts
