2 Product description
2.1 Common information about Copeland Stream™ semi-hermetic compressors
These guidelines cover Copeland Stream™ semi-hermetic compressors. The semi-hermetic
reciprocating compressor family consists of different ranges. The Stream™ series of 4M* and
6M* models ranges from 13 hp to 50 hp.
Cooling
capacity
(kW)
COP
-
Cooling
capacity
(kW)
COP
-
Cooling
capacity
(kW)
COP
-
4MF-13X 13 33.20 3.28 31.60 2.29 10.65 1.43 177
4MA-22X 22 34.60 3.41 32.70 2.39 10.45 1.44 178
4ML-15X 15 39.70 3.30 38.40 2.31 13.30 1.48 180
4MH-25X 25 39.90 3.30 38.50 2.37 12.40 1.44 187
4MM-20X 17 43.50 3.28 42.00 2.31 15.10 1.49 182
4MI-30X 27 43.70 3.30 42.80 2.37 14.40 1.47 188
4MT-22X 22 49.30 3.26 47.60 2.31 16.95 1.48 183
4MJ-33X 30 48.60 3.30 47.60 2.38 16.15 1.49 190
4MU-25X 25 55.10 3.20 53.10 2.27 18.60 1.45 186
4MK-35X 32 54.50 3.17 53.50 2.31 18.25 1.45 202
6MM-30X 27 65.80 3.21 64.20 2.30 22.70 1.45 215
6MI-40X 35 64.70 3.16 64.60 2.34 21.90 1.44 219
6MT-35X 32 73.60 3.17 72.40 2.30 25.60 1.47 221
6MJ-45X 40 72.60 3.16 72.40 2.32 24.30 1.45 223
6MU-40X 40 81.10 3.07 81.40 2.29 28.40 1.44 225
6MK-50X 50 80.70 3.05 80.90 2.29 27.30 1.41 230
Footprint
(mm)
Medium temperature
2)
High temperature
1)
Low temperature
3)
Displacement
(m
3
/h)
Nominal
horsepower
hp
Model
62
381 x 305
71
78
88
99
120
135
153
R404A
R134a
R404A
Net
weight
(kg)
1)
R134a Evaporating 5°C, condensing 50°C, suction superheat 10K, subcooling 0K
2)
R404A Evaporating -10°C, condensing 45°C, suction gas temperature 20°C, subcooling 0K
3)
R404A Evaporating -35°C, condensing 40°C, suction gas temperature 20°C, subcooling 0K
Table 1: Stream compressors range and performance
Stream semi-hermetic compressors are suitable for a wide range of applications in the form of
either single compressors, condensing units or as multi-compressor equipment.
The compressor is only one component which must be combined with many others to build a
functional and efficient refrigeration system.
Therefore the information in this manual relates to Copeland Stream semi-hermetic
compressors with standard equipment and accessories only.
2.2 About these guidelines
These guidelines are intended to enable users to ensure the safe installation, starting, operation
and maintenance of semi-hermetic compressors. They are not intended to replace the system
expertise available from system manufacturers.
2.3 Nomenclature
The model designation contains the following technical information about Stream compressors:
