Emerson Dixell XR70T Installing And Operating Instructions

1592040000 XR70T EN v1.1 2019.07.09 XR70T 22/40
oUt
oA4
Relay output oA4 configuration
LiG
Pr2
nu(0); CP1(1); dEF(2);
FAn(3); ALr(4); LiG(5);
AUS(6); db(7); onF(8);
HES(9); Cnd(10); CP2(11);
dF2(12); HEt (13); inv(14)
oUt
AOP
Alarm relay polarity
CL
Pr2
oP(0); CL(1)
inP
ibt
Base times for digital inputs
SEC
Pr1
SEC(0); Min(1)
inP
i1P
Digital input 1 polarity
CL
Pr1
oP(0); CL(1)
inP
i1F
Digital input 1 configuration
dor
Pr1
nu(0); dor(1); dEF(2);
AUS(3); ES(4); EAL(5);
bAL(6); PAL (7); FAn(8);
HdF(9); onF(10); LiG(11);
CC(12); EMt(13)
inP
did
Digital input 1 alarm delay (base time
depends on par. ibt)
0
Pr1
sec
0 to 255 min/sec
inP
i2P
Digital input 2 polarity
CL
Pr1
OP(0); CL(1)
inP
i2F
Digital input 2 configuration
EAL
Pr1
nu(0); dor(1); dEF(2);
AUS(3); ES(4); EAL(5);
bAL(6); PAL (7); FAn(8);
HdF(9); onF(10); LiG(11);
CC(12); EMt(13)
inP
d2d
Digital input 2 alarm delay (base time
depends on par. ibt)
0
Pr1
sec
0 to 255 min/sec
inP
nPS
Number of external pressure switch
alarms before stopping the regulation
0
Pr2
0 to 15
inP
OdC
Compressor and fan status after door
opening
no
Pr2
no(0); FAn(1); CPr(2); F-C(3)
inP
rrd
Regulation restart after door alarm
no
Pr2
n(0); Y(1)
ES
ErA
Energy saving algorithm
nu
Pr2
nu(0); bAS(1)
ES
HES
Energy saving mode temperature
differential
0
Pr1
°C
[-30°C to 30°C]
[-54°F to 54°F]
ES
LdE
Energy saving controls the lights (lights
OFF when energy saving is active)
no
Pr1
n(0); Y(1)
ES
StE
Period to switch from normal mode to
energy saving mode
00:00
Pr1
hh:mm
0 to 23h50min; nu
ES
EtS
Period to switch from energy saving
mode to normal mode
00:00
Pr1
hh:mm
0 to 23h50min; nu
ES
dS
Door opening time to switch from EtS to
StE
0
Pr1
sec
0 to 999 sec
Cnt
n1H
Number of activations for relay output
oA1 (thousands of)
Pr1
read only
Cnt
n1L
Number of activations for relay output
oA1 (units of)
Pr1
read only
Cnt
n2H
Number of activations for relay output
oA2 (thousands of)
Pr1
read only
Cnt
n2L
Number of activations for relay output
oA2 (units of)
Pr1
read only
Cnt
n3H
Number of activations for relay output
oA3 (thousands of)
Pr1
read only
Cnt
n3L
Number of activations for relay output
oA3 (units of)
Pr1
read only
Cnt
n4H
Number of activations for relay output
oA4 (thousands of)
Pr1
read only
Cnt
n4L
Number of activations for relay output
oA4 (units of)
Pr1
read only
Cnt
n5H
Number of total activations of digital
input 1 (thousand of)
Pr1
read only
Cnt
n5L
Number of total activations of digital
input 1 (units of)
Pr1
read only
Cnt
n6H
Number of total activations of digital
input 2 (thousand of)
Pr1
read only
Cnt
n6L
Number of total activations of digital
input 2 (units of)
Pr1
read only
