1592040000 XR70T EN v1.1 2019.07.09 XR70T 23/40
Cnt
F1H
Number of working hours for relay
output oA1 (thousands of)
Pr1
hours
read only
Cnt
F1L
Number of working hours for relay
output oA1 (units of)
Pr1
hours
read only
Cnt
F2H
Number of working hours for relay
output oA2 (thousands of)
Pr1
hours
read only
Cnt
F2L
Number of working hours for relay
output oA2 (units of)
Pr1
hours
read only
Cnt
F3H
Number of working hours for relay
output oA3 (thousands of)
Pr1
hours
read only
Cnt
F3L
Number of working hours for relay
output oA3 (units of)
Pr1
hours
read only
Cnt
F4H
Number of working hours for relay
output oA4 (thousands of)
Pr1
hours
read only
Cnt
F4L
Number of working hours for relay
output oA4 (units of)
Pr1
hours
read only
rtC
Hur
Hours
Pr1
read only
rtC
Min
Minutes
Pr1
read only
rtC
dAY
Day of the week
Pr1
read only
rtC
dYM
Day of the month
Pr1
read only
rtC
Mon
Month
Pr1
read only
rtC
YAr
Year
Pr1
read only
rtC
Hd1
First day of weekend
nu
Pr2
Sun(0) to SAt(6); nu(7)
rtC
Hd2
Second day of weekend
nu
Pr2
Sun(0) to SAt(6); nu(7)
rtC
iLE
Energy saving cycle starting time on
working days
00:00
Pr2
hh:mm
0.0 to 23h50min
rtC
dLE
Energy saving cycle duration on working
days
00:00
Pr2
hh:mm
0.0 to 24h00min
rtC
iSE
Energy saving cycle starting time on
weekends
00:00
Pr2
hh:mm
0.0 to 23h50min
rtC
dSE
Energy saving cycle duration on
weekends
00:00
Pr2
hh:mm
0.0 to 24h00min
rtC
dd1
Sunday defrost
no
Pr2
n(0); Y(1)
rtC
dd2
Monday defrost
no
Pr2
n(0); Y(1)
rtC
dd3
Tuesday defrost
no
Pr2
n(0); Y(1)
rtC
dd4
Wednesday defrost
no
Pr2
n(0); Y(1)
rtC
dd5
Thursday defrost
no
Pr2
n(0); Y(1)
rtC
dd6
Friday defrost
no
Pr2
n(0); Y(1)
rtC
dd7
Saturday defrost
no
Pr2
n(0); Y(1)
rtC
Ld1
1st defrost starting time
00:00
Pr2
hh:mm
0.0 to 23h50min(143);
nu(144)
rtC
Ld2
2nd defrost starting time
00:00
Pr2
hh:mm
0.0 to 23h50min(143);
nu(144)
rtC
Ld3
3rd defrost starting time
00:00
Pr2
hh:mm
0.0 to 23h50min(143);
nu(144)
rtC
Ld4
4th defrost starting time
00:00
Pr2
hh:mm
0.0 to 23h50min(143);
nu(144)
rtC
Ld5
5th defrost starting time
00:00
Pr2
hh:mm
0.0 to 23h50min(143);
nu(144)
rtC
Ld6
6th defrost starting time
00:00
Pr2
hh:mm
0.0 to 23h50min(143);
nu(144)
E2
MAP
Current configuration
0
Pr1
C-1(0); C-2(1)
E2
LdM
Restore default factory setting
0
Pr2
n(0); Y(1)
E2
rHA
Reset for HACCP function
0
Pr2
n(0); Y(1)
CoM
Adr
Serial address
1
Pr2
1 to 247
