Maximum time with compressor active: (0 to 255 min) if compressor working time
is over MCo, it will be stopped. MCo=0 means function disabled.
F(P1; P2) percentage for regulation: (0 to 100; 100=P1, 0=P2) it allows to set the
regulation according to the percentage of the first and second probe, as for the
following formula (rtr(P1-P2)/100 + P2).
Maximum duration for Pull Down: (0.0 to 24h00min, res. 10min) allows setting the
length of the PULL-DOWN cycle. Compressor stays on without interruption during CCt
time. This is useful, for instance, when the room is filled with new products.
Differential for Pull Down: (-12 to 12°C; -21 to 21°F) relative value to add to the
regulation SETPOINT and to use during any PULL-DOWN cycle.
Threshold for automatic activation of Pull Down in normal mode: (0.0 to 25.5°C;
0 to 45°F) upper threshold for auto activation of a PULL DOWN
Compressor ON time with faulty probe: (0 to 255min) time during which the
compressor is active in case of faulty thermostat probe. With Con=0 compressor is
always OFF.
Compressor OFF time with faulty probe: (0 to 255min) time during which the
compressor is OFF in case of faulty thermostat probe. With CoF=0 compressor is
always active.
Inverter compressor speed during ton (in percentage): 0 to 100%
Deactivation of the ONOFF compressor: (th1; th2) define when ONOFF compressor is
stopped. th1=when T<SET+HY; th2 when t<SET
Delay before activation of the second compressor (when T> SET + HY + HY1): 0 to
255 sec
Delay before deactivation of the second compressor: 0 to 255 sec
Minimum operating time of the second compressor: 0 to 255 sec
VARIABLE SPEED COMPRESSOR CONTROL
Differential for normal regulation (compressor cut-in): (0.1 to 25.5°C; 1 to 45°F)
Frequency output value with compressor stopped: ([0 Hz ÷ FMi])
Minimum drive speed (in percentage): (0 to PMA)
Maximum drive speed (in percentage): (PMi to 100%)
Compressor speed variation (increment) when temperature is increasing: (1 to
100 Hz/min, StP) StP = means that inverter speed is adapted immediately on
temperature variation
Compressor speed variation (decrement) when temperature is decreasing: (0 to
100 Hz/min, StP, nu) StP = means that inverter speed is adapted immediately on
temperature variation; nu = speed decrement disabled
Compressor speed variation (decrement) after any Pull Down: (0 to 100 Hz/min,
StP, nu) StP = means that inverter speed is adapted immediately on temperature
variation; nu = speed decrement disabled
Variable Speed Drive (in percentage) during any Pull Down: 0 to 100 %
Time with Variable Speed Drive at minimum before stopping it: 0 to 999 min
Variable Speed Drive (in percentage) in case of any error probe: PMi to PMA
Variable Speed Drive (in percentage) during any defrost: PMi to PMA
Variable Speed Drive (in percentage) during a pre-defrost phase: PMi to PMA
Differential for deadlock control: 0.1 to 1.0°C
Compressor speed increment during any deadlock condition: 1 to 10Hz
Continuous mode regulation when normal mode: (n; Y)
Continuous mode regulation when energy saving mode: (n; Y)
Minimum compressor speed for activating lubrication control (valid only for
Variable Speed Drive): (nu, 1÷99%, OFF) nu = function disabled; OFF = compressor
is stopped for tMA time
Compressor running time below the MnP threshold: (0.0 to 24h00min)
Lubrication control interval: 0 to 255 min
Temperature probe selection: ntC; PtC; PT1000
Probe P1 calibration: (-12.0 to 12.0°C; -21 to 21°F) allows to adjust possible offset
of the thermostat probe.
Probe P2 presence: (n; Y) n = not present, the defrost stops by time;
Y = present, the defrost stops by temperature.
Probe P2 calibration: (-12.0 to 12.0°C; -21 to 21°F) allows to adjust possible offset
of the evaporator probe.
Probe P3 presence: (n; Y) n = not present, the terminals 18-20 operate as digital
input; Y = present, the terminals 18-20 operate as third probe.
Probe P3 calibration: (-12.0 to 12.0°C; -21 to 21°F) allows to adjust possible offset
of the third probe.
Probe P4 presence: (n; Y) n = not present; Y = present
Probe P4 calibration: (-12.0 to 12.0°C; -21 to 21°F) allows to adjust possible offset
of the fourth probe
Temperature measurement unit: (°C; °F) °C = Celsius; °F = Fahrenheit.
WARNING: When the measurement unit is changed the SET point and the values of
the parameters HY, LS, US, ot, ALU and ALL have to be checked and modified (if
necessary).
Resolution for °C: (in=1°C; dE=0.1°C) allows decimal point display.
Probe visualized (P1; P2, P3, P4, SET, dtr) it selects which probe is displayed by the
instrument. P1 = Thermostat probe; P2 = Evaporator probe; P3 = Third probe (only for
model with this option enabled); P4 = Fourth probe, SET = set point; dtr = percentage
of visualization.
Temperature visualization delay: (0 to 20min00s; res. 10 sec) when the temperature
increases, the display is updated of 1°C or 1°F after this time.
Visualization percentage=F(P1;P2): (1 to 99; 99=P1, 1=P2) if Lod=dtr it allows to set
the visualization according to the percentage of the first and second probe, as for the
following formula (dtr(P1-P2)/100 + P2).
Defrost mode (only for controller with RTC): rtC=Real Time Clock mode. Defrost
time follows dd1...dd6 and Ld1…Ld6 parameters on working days. in=interval mode.
The defrost starts when the time idF is expired.
Defrost type: (EL; in) EL = electrical heater; in = hot gas.
Probe selection for defrost control: (nP; P1; P2; P3; P4) nP = no probe;
P1 =thermostat probe; P2 = evaporator probe; P3 =configurable probe; P4 = Probe on
Hot Key plug.
Defrost end temperature: (-55 to 50°C; -67 to 122°F) (enabled only when EdF=Pb)
sets the temperature measured by the evaporator probe, which causes the end of
defrost.
Interval between two consecutive defrost cycles: (0 to 120 hours) determines the
interval of time between two defrost cycles.
Maximum length for any defrost: (0 to 255min) when P2P=n, (not evaporator probe:
timed defrost) it sets the defrost duration. When P2P=Y (defrost end based on
temperature) it sets the maximum length for defrost.
Start defrost delay: (0 to 255 sec) when a defrost starts, the compressor will be
stopped and the defrost output delayed. If dSd=0 this function is disabled.
Compressor stop before activating any defrost: (0 to 255 sec) is used to delay the
compressor restart when the defrost is managed for inversion of cycle (hot-gas).
Displaying during any defrost: (rt; it; Set; dEF) rt = real temperature;
it = temperature at defrost start; Set = set point; dEF = “dEF” label.
Delay for display temperature update after any defrost: (0 to 255min) sets the
maximum time between the end of a defrost and the beginning of the visualization of
the real room temperature.
Draining time: (0 to 120min) time interval between reaching defrost termination
temperature and the restoring of the control’s normal operation. This time allows the
evaporator to eliminate water drops that might have formed due to defrost.
Time with drain heater activated after drainig time Fdt (valid is oAx=HEt): (0.0 to
24h00min, res. 10 min) the heating elements stay on for this time after finishing the
dripping phase.
Defrost after power on: (n; Y) n = after the idF time or following RTC, Y = immediately.
Pre-defrost time: (0 to 255 min) it is used to sub freeze the goods before activating
any defrost. The regulation setpoint is modified to SET-1°C or SET-2°F during this
interval. If dAF=0 this function is disabled.
Probe selection for evaporator fan: (nP; P1; P2; P3; P4) nP = no probe;
P1 =thermostat probe; P2 = evaporator probe; P3 =configurable probe; P4 = Probe on
Hot Key plug.
Evaporator fan stop temperature: (-50 to 50°C; -55 to 122°F) setting of temperature,
detected by evaporator probe, above which fans are always OFF.
Differential for evaporator fan regulator: (0.1 to 25.5°C; 1 to 45°F)
Evaporator fan mode operation: (C-n; o-n; C-Y; o-Y) C-n = runs with the compressor,
OFF during defrost; o-n = continuous mode, OFF during defrost; C-Y = runs with the
compressor, ON during defrost; o-Y = continuous mode, ON during defrost.
Evaporator fan delay after defrost: (0 to 255min) interval between the end of a
defrost and the next evaporator fans start.
Temperature differential for evaporator fan activation: (0 to 59°C; 0 to 90°F) (N.B.:
FCt=0 means function disabled) if the difference of temperature between the
evaporator and the room probes is higher than FCt value, the fans will be switched on.
Evaporator fan controlled during any defrost: (n;Y)
Evaporator fan ON in normal mode (with compressor OFF): (0 to 15min)
with Fnc=C_n or C_Y, (fan activated in parallel with compressor) it sets the evaporator
fan ON cycling time when the compressor is off. With Fon=0 and FoF≠0 the fan are
always off, with Fon=0 and FoF=0 the fan are always off.
Evaporator fan OFF in normal mode (with compressor OFF): (0 to 15min)
With FnC=C_n or C_Y, (fan activated in parallel with compressor) it sets the evaporator
fan off cycling time when the compressor is off.
With Fon=0 and FoF≠0 the fan are always off, with Fon=0 and FoF=0 the fan are
always off.
Probe selection for condenser fan: (nP; P1; P2; P3; P4) nP = no probe;
P1 =thermostat probe; P2 = evaporator probe; P3 =configurable probe; P4 = Probe on
Hot Key plug.
Set Point for condenser fan regulator: (-100.0 to 150.0°C; -148 to 302°F)
Differential for condenser fan regulator: (0.1 to 25,5°C; 1 to 45°F)
Condenser fan mode operation: (C-n; o-n; C-Y; o-Y) C-n = runs with the compressor,
OFF during defrost; o-n = continuous mode, OFF during defrost; C-Y = runs with the
compressor, ON during defrost; o-Y = continuous mode, ON during defrost
Condenser fan activated when compressor off (valid if FCC=C-n, C-Y): (0 to 999
sec
Type of action for auxiliary regulator: (CL; Ht) CL=cooling; Ht = heating
Set point for auxiliary regulator: (-100.0 to 150.0°C; -148 to 302°F)
Differential for auxiliary regulator: (0.1 to 25.5°C; 1 to 45°F)
Probe selection for auxiliary regulator: (nP; P1; P2; P3; P4) nP = no probe;
P1 =thermostat probe; P2 = evaporator probe; P3 =configurable probe; P4 = Probe on
Hot Key plug.
Auxiliary regulator disabled during any defrost: (n; Y) n=the auxiliary relay
operates during defrost. Y=the auxiliary relay is switched off during defrost.
Temperature alarm probe selection: (nP; P1; P2; P3; P4) nP = no probe, the
temperature alarms are disabled; P1 = Probe 1 (Thermostat probe); P2 = Probe 2
(evaporator probe);
P3 = Probe 3 (display probe); P4 = Fourth probe.
Temperature alarms configuration: (Ab; rE) Ab = absolute temperature, alarm
temperature is given by the ALL or ALU values. rE = temperature alarms are referred
to the set point. Temperature alarm is enabled when the temperature exceeds the
[SET+ALU] or [SET-ALL] values.
Maximum temperature alarm:
If ALC=Ab: [ALL to 150.0°C or ALL to 302°F]
If ALC=rE: [0.0 to 50.0°C or 0 to 90°F]
when this temperature is reached the alarm is enabled, after the Ald delay time.
