22. DEFAULT SETTING VALUES
LABEL
Description
VALUE
LEVEL
SEt
Regulation Set Point
-20.0
rtC
RTC menu visualization
Pr1
LS
Minimum Set point
-30.0
Pr2
US
Maximum Set point
10.0
Pr2
Hy
Differential for normal regulation
1.0
Pr1
odS
Outputs delay activation after power on
3
Pr2
AC
Anti-short cycle delay
5
Pr2
AC1
Anti-short cycle delay for second compressor
0
Pr2
MCo
Maximum time with compressor on
0
Pr2
rtr
Percentage for regulation=F(P1; P2) (100=P1; 0=P2)
100
Pr2
CCt
Maximum duration for Pull Down
3.00
Pr1
CCS
Differential for Pull Down (SET+CCS or
SET+HES+CCS)
-2.0
Pr1
oHt
Threshold for automatic activation of Pull Down in
normal mode (SET+HY+oHt)
10.0
Pr2
Con
Compressor ON time with faulty probe
30
Pr2
CoF
Compressor OFF time with faulty probe
5
Pr2
PbC
Probe selection
ntC
Pr2
ot
Probe P1 calibration
0.0
Pr1
P2P
Probe P2 presence
yes
Pr2
oE
Probe P2 calibration
0.0
Pr2
P3P
Probe P3 presence
no
Pr2
o3
Probe P3 calibration
0.0
Pr2
P4P
Probe P4 presence
no
Pr2
o4
Probe P4 calibration
0.0
Pr2
Hy1
Differential for proportional regulation in normal mode
1.0
Pr2
Fr0
Frequency output value with compressor stopped
0
Pr2
PMi
Minimum compressor speed (in percentage)
20
Pr2
PMA
Maximum compressor speed (in percentage)
100
Pr2
voS
Compressor speed variation (increment) when
temperature is increasing
1
Pr2
vo2
Compressor speed variation (decrement) when
temperature is decreasing
2
Pr2
vo3
Compressor speed variation (decrement) after any
Pull Down
5
Pr2
PdP
Compressor speed during any Pull Down
100
Pr2
t1F
Time with compressor speed at PMI before stopping
the compressor
1
Pr2
SPi
Compressor speed (in percentage) in case of any
error probe
70
Pr2
Aod
Compressor speed (in percentage) during any defrost
(valid if tdf=in)
70
Pr2
AoF
Compressor speed during a pre-defrost phase (valid if
tdf=in)
50
Pr2
tHv
Maximum time for compressor speed variation
60
Pr2
tLv
Minimum time for compressor speed variation
20
Pr2
dtC
Temperature sampling time
10
Pr2
tH1
Differential for deadlock control
1.0
Pr2
oFS
Compressor speed increment during any deadlock
condition (in Hz)
1
Pr2
CMn
Continuous mode during normal mode
yes
Pr2
CME
Continuous mode during energy saving mode
yes
Pr2
MnP
Minimum compressor speed for activating lubrication
control (valid only for variable speed compressors)
30
Pr2
tMi
Compressor running time below the MnP threshold
01:00
Pr2
tMA
Interval of time with compressor a PMA during
lubrication control
1
Pr2
CF
Temperature measurement unit: Celsius; Fahrenheit
°C
Pr1
rES
Temperature resolution: decimal, integer
dE
Pr1
Lod
Probe displayed on the display
P1
Pr1
dLy
Display temperature delay
00:00
Pr1
dtr
Visualization percentage=F(P1; P2) (ex: dtr=1 means
VALUE=0.01*P1+0.99*P2)
99
Pr1
EdF
Defrost mode
in
Pr2
tdF
Defrost type: electrical heating, hot gas
in
Pr2
dFP
Probe selection for defrost control
P2
Pr2
dtE
Defrost termination temperature
4.0
Pr2
idF
Interval between two consecutives defrost cycles
24
Pr2
MdF
Maximum length for defrost
45
Pr2
dSd
Start defrost delay
0
Pr2
StC
Compressor stop time before starting any defrost
5
Pr2
dFd
Displaying during defrost
it
Pr1
dAd
Delay for display temperature update after any defrost
20
Pr1
Fdt
Draining time
5
Pr2
Hon
Drain heater activated after draining time Fdt (valid if
oAx=Het)
00:00
Pr2
dPo
Defrost after power on
no
Pr2
dAF
Defrost delay after Pull Down
3
Pr2
FAP
Probe selection for evaporator fan
P2
Pr2
FSt
Evaporator fan stop temperature
-10.0
Pr2
HyF
Differential for evaporator fan regulator
1.0
Pr2
FnC
Evaporator fan mode operation
O_n
Pr2
Fnd
Evaporator fan delay after defrost
3
Pr2
FCt
Differential of temperature for forced activation of
evaporator fan (o=disabled)
0
Pr2
Ft
Evaporator fan controlled during defrost
no
Pr2
Fon
Evaporator fan ON time (with compressor OFF)
0
Pr2
FoF
Evaporator fan OFF time (with compressor OFF)
0
Pr2
FAC
Probe selection for condenser fan
nP
Pr2
St2
Regulation Set Point 2 for condenser fan
35.0
Pr2
Hy2
Differential for Set Point 2 for condenser fan regulator
1.0
Pr2
FCC
Condenser fan mode operation
O_n
Pr2
FCo
Condenser fan on after switching off the compressor
0
Pr2
ACH
Kind of action for auxiliary regulator
CL
Pr2
SAA
Set point for auxiliary regulator
0.0
Pr2
SHy
Differential for auxiliary regulator
1.0
Pr2
ArP
Probe selection for auxiliary regulator
nP
Pr2
Sdd
Auxiliary regulator disabled during any defrost
no
Pr2
ALP
Probe selection for temperature alarms
P1
Pr1
ALC
Temperature alarms configuration: relative, absolute
rE
Pr1
ALU
Maximum temperature alarm
8.0
Pr1
ALL
Minimum temperature alarm
7.0
Pr1
AFH
Temperature alarm recovery differential
1.0
Pr1
ALd
Temperature alarm delay
10
Pr1
dAo
Temperature alarm delay after power-on
24.00
Pr1
AP2
Probe selection for second temperature alarms
nP
Pr2
AL2
Second low temperature alarm
-40.0
Pr2
AU2
Second high temperature alarm
110.0
Pr2
AH2
Differential for second temperature alarm recovery
1.0
Pr2
Ad2
Second temperature alarm delay
5
Pr2
dA2
Delay for second temperature alarm after power-on
01:00
Pr2
bLL
Compressor off due to second low temperature alarm
no
Pr2
AC2
Compressor off due to second high temperature alarm
yes
Pr2
SAF
Differential for anti-freezing control
5.0
Pr2
tbA
Alarm relay switched off by pushing any key
yes
Pr2
oA1
Relay output oA1 configuration
LiG
Pr2
oA2
Relay output oA2 configuration
dEF
Pr2
oA3
Relay output oA3 configuration
Fan
Pr2
oA4
Relay output oA4 configuration
ALr
Pr2
oAn
Analogue output configuration
FrE
Pr2
AOP
Alarm relay polarity
CL
Pr2
i1P
Digital input 1 polarity
CL
Pr1
i1F
Digital input 1 configuration
dor
Pr1
did
Digital inputs 1 alarm delay
1
Pr1
nPS
Number of pressure alarm switch before stopping the
regulation (Lock alarm)
5
Pr1
OdC
Compressor and fan status after door opening
F-C
Pr1
rrd
Regulation restart after open door alarm
yes
Pr1
HES
Differential for energy saving mode
0
Pr1
