Emerson EWD7003 - Page 13

1-6-3 E58T0DC
[4] AV CBA
[5] DVD Main
CBA Unit
(S-5)
(S-5)
(S-3
)
(S-4)
CN601
CN2001
CN401
(S-4)
[6] Function
CBA
Fig. D5
(S-7)
[8] Rear Pane
l
(S-6)
[7] Main CBA
Holder
Fig. D6
Rotate this roulette in
the direction of the arrow
A
View for A
HOW TO MANUAL EJECT
1. Remove the Top Case.
2. Rotate the roulette in the direction of the arrow as
shown below.
