MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTE:
Parts that are not assigned part numbers (---------) are
not available.
Ref. No. Description Part No.
A1X FRONT ASSEMBLY E57T0UD 0VM204012
A2 TRAY PANEL E57T0UD 0VM203945
A13 FOOT(REAR) E5710UD 0VM415007
A15 MAIN CHASSIS E57S0UD 0VM101219
A16 TOP COVER E57S0UD 0VM101220
A17 REAR PANEL E57S0UD 0VM203877
A19 HOLDER, EAS(H9410UD) MAKER NO.EM150DR 0VM415877
A21 LABEL, MODEL NO. E58T0UD ----------
A22 LABEL, BAR CODE HB400UD or ----------
LABEL, BAR CODE E57T0UD ----------
A23 LABEL, TELEPHONE NUMBER H7931UD(EMER-
SON)
----------
1B1 DVD MECHA (THIN TYPE) 0838 VCDVM040 N79F1GVM
2B3 HOLDER, MAIN PCB E5700UD 0VM305832B
2L011 SCREW, C-TIGHT M3X5 BIND HEAD + GBCC3050
2L021 SCREW, S-TIGHT M3X8 BIND + CHROME GBMS3080
2L031 SCREW, C-TIGHT M3X6 BIND HEAD GBMC3060
2L041 SCREW, B-TIGHT M3X8 BIND HEAD + GBKB3080
2L071 SCREW, C-TIGHT M3X6 BIND HEAD GBMC3060
2L101 SCREW, C-TIGHT M3X6 BIND HEAD GBMC3060
2L105 P-TIGHT SCREW 3X8 BIND + GBMP3080
PACKING
S1 GIFT BOX CARTON E57T0UD 0VM306042
S2 STYROFOAM E57S0UD 0VM101231
S4 UNIT, BAG E5500UD 0VM411683
S5 PAD E57S0UD 0VM414757
ACCESSORIES
X1 REMOTE CONTROL UNIT DVD 0842 VCDVR040 or NA604UD
REMOTE CONTROL UNIT DVD 0842 VCDVR040 NA654UD
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X4 ACCESSORY BAG E56A0UD 0VM413280
X5 AV CORD TSCKA-Y/RW100 or WPZ0102TM015
AV CORD RCA(M*2)TO RCA(M*2) WPZ0102LTE01
X10# OWNER'S MANUAL E57T0UD 0VMN03459A
X14 DVD RENTAL SHEET H9410UD 0VMN03694
X36 RETURN STOP SHEET E57T0UD 0VM414933
