Emerson EWD7003 - IC Pin Function Descriptions

1-13-1 E58T0PIN
IC PIN FUNCTION DESCRIPTIONS
IC2001 [ PT6313-S-TP ]
Pin
No.
In/Out
Signal
Name
Name Function
1 In FP-CLK
Clock Input
2 In FP-STB
Serial Interface Strobe
3 In K1
Key Data 1 Input
4 In K2
Key Data 2 Input
5 - VSS
GND
6 - VDD
Power Supply
7 Out KEY-1
Key Source-1
8 Out KEY-2
Key Source-2
9 Out KEY-3
Key Source-3
10 Out KEY-4
Key Source-4
11 - NU
Not Used
12 - NU
Not Used
13 - NU
Not Used
14 - NU
Not Used
15 - NU
Not Used
16 - NU
Not Used
17 Out PLAY LED
Play LED Display Signal
18 Out
DISC-IN
LED
Loading Disc LED Display
Signal
19 - NU
Not Used
20 - NU
Not Used
21 - NU
Not Used
22 - NU
Not Used
23 - NU
Not Used
24 - VDD
Power Supply
25 - VSS
GND
26 In OSC
Oscillator Input
27 Out FP-DOUT
Serial Data Output
28 In FP-DIN
Serial Data Input
