FRONT CBA
R1023 CHIP RES.(1608) 1/16W F 2.4k Ω or RRXGFR5Z0242
CHIP RES.(1608) 1/10W F 2.4k Ω RRXAFR5Z2401
R1025 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1029 CARBON RES. 1/6W J 470k Ω or RCX6JATZ0474
CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1032 CARBON RES. 1/6W J 3.3k Ω or RCX6JATZ0332
CARBON RES. 1/4W J 3.3k Ω RCX4JATZ0332
R1035 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1043 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7ZU001
METAL OXIDE FILM RES. 1W J 2.7 Ω RN012R7KE009
R1044 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1059 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1067 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1068 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R1069 CARBON RES. 1/6W J 560 Ω or RCX6JATZ0561
CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R1072 CHIP RES.(1608) 1/10W J 680 Ω RRXAJR5Z0681
R1073 METAL RESISTOR 2W J 39 Ω or RN02390ZU001
FIXED METAL OXIDE FILM RES. 2W J 39 Ω RN02390KE007
R1074 RECTIFIER DIODE 1N4005 NDQZ001N4005
R1075 CHIP RES.(1608) 1/10W F 10 Ω or RRXAFR5H0100
CHIP RES. 1/16W F 10 Ω RRXGFR5Z0100
R1076 CHIP RES.(1608) 1/16W F 1.8k Ω or RRXGFR5Z0182
CHIP RES. 1/16W F 1.8k Ω RRXGFR5Z1801
R1080 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R1081 CHIP RES. 1/10W F 51 Ω RRXAFR5H0510
R1086 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1095 PCB JUMPER D0.6-P12.5 JW12.5T
R1097 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1098 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1201 CHIP RES.(1608) 1/16W F 20k Ω or RRXGFR5Z0203
CHIP RES.(1608) 1/10W F 20k Ω RRXAFR5Z2002
R1202 CHIP RES.(1608) 1/16W F 20k Ω or RRXGFR5Z0203
CHIP RES.(1608) 1/10W F 20k Ω RRXAFR5Z2002
R1207 CHIP RES.(1608) 1/10W J 8.2k Ω RRXAJR5Z0822
R1208 CHIP RES.(1608) 1/10W J 8.2k Ω RRXAJR5Z0822
R1209 CHIP RES. 1/16W F 30k Ω RRXGFR5Z0303
R1210 CHIP RES. 1/16W F 30k Ω RRXGFR5Z0303
R1211 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1212 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1221 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1222 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1223 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1224 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1225 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1226 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1227 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1228 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1235 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1236 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1237 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1238 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1245 CHIP RES.(1608) 1/10W J 10 Ω RRXAJR5Z0100
R1351 CHIP RES.(1608) 1/10W J 1.8k Ω RRXAJR5Z0182
R1352 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1353 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1354 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1355 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1356 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1392 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1396 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
Ref. No. Description Part No.
R1397 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1402 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1422 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1442 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1443 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1462 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1482 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1613 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R2001 CARBON RES. 1/4W J 150 Ω RCX4JATZ0151
R2002 CARBON RES. 1/4W J 150 Ω RCX4JATZ0151
R2003 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R2015 CHIP RES.(1608) 1/10W J 68k Ω RRXAJR5Z0683
R2016 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2017 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2026 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682
R2028 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2031 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R2042 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2048 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2049 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2050 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2051 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2053 CARBON RES. 1/6W J 10 Ω or RCX6JATZ0100
CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R2054 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R2055 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R2056 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R2057 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2058 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
MISCELLANEOUS
AC1001# AC CORD PB8K9F9110A-055 WAC0162LW003
F1001# FUSE 1A/250V or PAGA20CW3102
# FUSE 1A/250V PAGG20CAG102
FH1001 FUSE HOLDER MSF-015 XH01Z00LY001
FH1002 FUSE HOLDER MSF-015 XH01Z00LY001
J2576 CERAMIC CAP.(AX) CH J 470PF/50V CA1J471TU008
JK1202 RCA JACK(BLACK) MSP-251V-01 NI or JXRL010LY070
RCA JACK(BLACK) AV1-28A-1 JXRL010RP024
JK1401 S TYPE JACK MDC-050V-2.4 JXEL040LY001
JK1404 RCA JACK MSP-246V34-65NI-FELF or JXRL060LY082
RCA JACK MSD-246V-65NI/PBSN JXRL060LY069
RM2001 REMOTE RECEIVER MIM-93M6DKF or USESJRSUNT01
REMOTE RECEIVER PIC-37042LU USESJRSKK033
SA1001# SURGE ABSORBER PVR-10D471KB or NVQZ10D471KB
# SURGE ABSORBER CNR-10D471K NVQZR10D471K
T1001# PULSE TRANS CSA-SW0340B or LTT00CPSA148
# PULSE TRANS 03711 LTT00CPKT113
VR1002 PCB JUMPER D0.6-P5.0 JW5.0T
Ref. No. Description Part No.
FRONT CBA
Consists of the followings
----------
CONNECTOR
CN2002 6P FFC AV PCB TO SW PCB WX1E5800-003
RESISTORS
R2104 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2105 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2106 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2107 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
Ref. No. Description Part No.
To Next Page
