Instruction Manual
D102087X012
585C Actuator
October 2013
23
Parts Kits
Actuator Size Parts Kit Description Parts Kit Number
25
O-ring(containskeys7,8,and9)
Backup ring (key 25) for size 50 actuators only
R585CX00252
50 R585CX00502
60 (2-inch maximum travel)
O-ring(containskeys7,8,9,and27)
Pistonrodboot(key29)andSnapring(keys30and31)
R585CX00012
60 (4-inch maximum travel)
O-ring(containskeys7,8,9,and27)
Pistonrodboot(key29)andSnapring(keys30and31)
R585CX00022
60 (2-, 4-, and 8-inch maximum travel w/ handwheel)
(8-inch maximum travel)
O-ring(containskeys7,8,9,and27) R585CX00032
68 (2-, 4-, and 8-inch maximum travel w/ handwheel) O-ring (contains keys 7, 8, 9, 27, and 112) R585CX00102
68 (2-, 4-, and 8-inch maximum travel)
80 (8-inch maximum travel)
80 (2-, 4-, and 8-inch maximum travel w/ handwheel)
O-ring(containskeys7,8,9,and27) R585CX00042
80 (4-inch maximum travel)
O-ring(containskeys7,8,9,and27)
Pistonrodboot(key29)andSnapring(keys30and31)
R585CX00052
100 (4-inch maximum travel)
O-ring(containskeys7,8,9,and27)
Pistonrodboot(key29)andSnapring(keys30and31)
R585CX00062
100 (8-inch maximum travel)
4- and 8-inch maximum travel w/ handwheel)
O-ring(containskeys7,8,9,and27) R585CX00072
130 (4-inch travel)
O-ring(containskeys7,8,9,and27)
Pistonrodboot(key29)andSnapring(keys30and31)
R585CX00082
130 (8-inch travel)
(4- and 8-inch travel with handwheel)
O-ring(containskeys7,8,9,and27) R585CX00092
