Instruction Manual
D102087X012
585C Actuator
October 2013
9
Handwheel Specifications
Table 9. Fisher 585C Handwheel Specifications
ACTUATOR SIZE
HANDWHEEL
MOUNTING
HANDWHEEL
DIAMETER
TURNS PER mm
TRAVEL
MAXIMUM RIM
FORCE REQUI RED
HANDWHEEL
OUTPUT FORCE
HANDWHEEL
WEIGHT
mm Newtons Newtons kg
25
Top-Mounted
356 0.5 325 12,810 17
50 482 0.5 445 23,790 20
60
(1)
Integral
Side-Mounted
203 0.6 276 40000 28
60
(2)
356 0.6 160 40000 30
68
(1)
203 0.6 276 40000 30
68
(2)
356 0.6 160 40000 33
80 432 0.4 423 50000 35
100 432 0.4 623 75600 94
130 432 0.4 623 75600 123
ACTUATOR SIZE
HANDWHEEL
MOUNTING
HANDWHEEL
DIAMETER
TURNS PER INCH
TRAVEL
MAXIMUM RIM
FORCE REQUI RED
HANDWHEEL
OUTPUT FORCE
HANDWHEEL
WEIGHT
Inches Pounds Pounds Pounds
25
Top-Mounted
14 12 73 2880 37
50 19 12 100 53 50 45
60
(1)
Integral
Side-Mounted
8 16 62 9000 61
60
(2)
14 16 36 9000 66
68
(1)
8 16 62 9000 66
68
(2)
14 16 36 9000 71
80 17 10 95 11250 77
100 17 10 140 17000 208
130 17 10 140 17000 272
1. 2 and 4 inch maximum travel constructions.
2. 8 inch maximum travel construction.
Figure 2. Fisher 585C Piston Actuator
with Handwheel
E0410
Figure 3. Fisher 585C Piston Actuator
with Spring Return
W7447-1
PISTON
O-RING
