Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
February 2021
21
Figure 20. Packing and Belleville Spring Stacking Order
7
10
10
12
8
12
16
43
3
11
LUBRICATE WITH 3mm (1/8 INCH
BEAD) OF SUPPLIED HIGH
PERFORMANCE FLUORINATED
GREASE (KEY 44)
LUBRICATE WITH 3mm (1/8
INCH BEAD) OF SUPPLIED HIGH
PERFORMANCE FLUORINATED
GREASE
FEMALE PACKING ADAPTOR
MALE PACKING ADAPTOR
PACKING RING
LUBRICATION LOCATIONS
ON PACKING
9
