Instruction Manual
D100399X012
EW Valve
July 2017
44
Figure 25. FGM Gasket Detail with Optional Drain Plug
FULL‐CAPACITY TRIM DETAIL
FGM GASKETS ALSO MUST BE
INSTALLED WHERE REQUIRED
IN SEAT RING AREA PER
FIGURE 22, 23, OR 24
RESTRICTED‐TRIM DETAIL
A2713*
