DVC6000f Series
March 2006
5-42
Table 5-13. Transducer Block Parameter Definitions (Continued)
Label
PARAMETER_NAME
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
FINAL_POSITION_VALUE
17
Data Type: DS-65
In Travel Control:
Valve travel in %,
decharacterized to correlate with
Setpoint (FINAL_VALUE [13]).
In Pressure Control:
Implied valve
travel as a % of pressure range,
decharacterized to correlate with
Setpoint (FINAL_VALUE [13]).
Controls AI channel 3.
Travel Status (DeChar)
STATUS
17.1 RO N/A N/A N/A
Travel (DeChar)
VALUE
17.2 RO N/A −25 to 125% N/A
Tvl Prop Gain
SERVO_GAIN
18 RW
MAN
OOS
> = 0 4.4 SETUP
Data Type: Float
Travel Control Only. Gain of servo.
Tvl Integral Gain
SERVO_RESET
19 RW
MAN
OOS
> = 0 , = 0 causes wind
down
9.4 SETUP
Data Type: Float
Travel Control Only. If set to 0, will
cause integrator to wind down.
Tvl Velocity Gain
SERVO_RATE
20 RW
MAN
OOS
> = 0 3.0 SETUP
Data Type: Float
Travel Control Only. Rate of servo.
Actuator Fail Action
ACT_FAIL_ACTION
21 RW
MAN
OOS
0=Uninitialized
1=Self Closing
2=Self Opening
1=
Self Closing
SETUP
Data Type: Enum
Action performed by actuator in the
event of air pressure.
Actuator Manufacturer Id
ACT_MAN_ID
22 RW ALL 0x5100 SETUP
Data Type: Uint32
The actuator manufacturer
identification number.
Actuator Model Number
ACT_MODEL_NUM
23 RW ALL Null SETUP
Data Type: Visible String
Model number of actuator.
Actuator Serial Number
ACT_SN
24 RW ALL Null SETUP
Data Type: Visible String
Serial number of actuator.
Valve Manufacturer Id
VALVE_MAN_ID
25 RW ALL 0x5100 SETUP
Data Type: Uint32
The valve manufacturer
identification number.
Valve Model Number
VALVE_MODEL_NUM
26 RW ALL Null SETUP
Data Type: Visible String
The valve model number.
Valve Serial Number
VALVE_SN
27 RW ALL Null SETUP
Data Type: Visible String
The valve serial number.
Valve Style
VALVE_TYPE
28 RW ALL
1=Sliding Stem
2=Rotary
1=Sliding Stem SETUP
Data Type: Enum
Selects Rotary or Sliding Stem. For
informational purposes only.
Calib Location
XD_CAL_LOC
29 RW ALL Null CAL
Data Type: Visible String
Where device was last calibrated.
Calib Date
XD_CAL_DATE
30 RW ALL Uninitialized CAL
Data Type: Date
Date of last calibration.
Calib Person
XD_CAL_WHO
31 RW ALL Null CAL
Data Type: Visible String
Name of person performing last
calibration.
SETPOINT_D
32
Data Type: DS_66
SETPOINT_D is not updated
unless the DO block is selected in
FEATURE_SEL.
STATUS indicates the validity of
value, set by the DO block
OUT.STATUS
VALUE is the discrete value of
setpoint. Only values of 0, 1, or
increments of 5 up to 95 are
allowed. Written by DO channel 22.
Setpoint(D) Status
STATUS
32.1 RW
MAN
OOS
NONE
Setpoint(D)
VALUE
32.2 RW
MAN
OOS
0 = closed 1 = open
5,10,15.. = %
NONE
TRAVEL_D
33
Data Type: DS_66
STATUS indicates the validity of
VALUE.
VALUE: 0=closed , 1=open
5,10,15.. = %. Controls DI Channel
23
Travel(D) Status
STATUS
33.1 RO N/A N/A
Travel (D)
VALUE
33.2 RO N/A
0 = closed 1 = open
5,10,15.. = %
N/A
−Continued−
