Emerson LC195EM82 User Manual

4-1 A81N0DC
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps for the
cabinet parts, and the CBA in order to gain access to
item(s) to be serviced. When reassembling, follow the
steps in reverse order. Bend, route and dress the
cables as they were.
2. Disassembly Method
Note:
(1) Order of steps in procedure. When reassembling,
follow the steps in reverse order. These numbers
are also used as the Identification (location) No. of
parts in figures.
(2) Parts to be removed or installed.
(3) Fig. No. showing procedure of part location
(4) Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
P = Spring, L = Locking Tab, S = Screw,
CN = Connector
* = Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)
(5) Refer to the following "Reference Notes in the
Table."
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
[1] Stand Base D1 2(S-1), 2(S-2), 4(S-3) ---
[2]
Stand
Hinge
D1 --------------- ---
[3]
Stand
Cover
D1 --------------- ---
[4]
Rear
Cabinet
D1 7(S-4) ---
[5]
Junction
CBA
D2
D3
*CN705, *CN706,
*WH1101B,
*WH1151B
---
[6]
Function
CBA
D2
D3
3(S-5) ---
[7]
IR Sensor
CBA
D2
D3
2(S-6) ---
[2] Stand Hinge
[3] Stand Cover
[4] Rear Cabinet
[1] Stand Base
[14] Speaker (s)
[5] Junction CBA
[8] Jack Holder
[10] DTV Module
CBA Unit
[7] IR Sensor
CBA
[6] Function CBA
[11] Main CBA
[12] Tilt Stand
Holder
[9] Digital Main
CBA Unit
[13] LCD Module
[15] Front Cabinet
[8] Jack Holder D2 (S-7) ---
[9]
Digital Main
CBA Unit
D2
D3
4(S-8), *CN1501,
*CN1502, *CN1503,
*CN1504, *CN1901,
*CN1902
---
[10]
DTV
Module
CBA Unit
D2
D3
7(S-9), *CN61,
*CN401, *CN402,
*CN801A, *CN802A,
Module PCB Holder
---
[11] Main CBA
D2
D3
--------------- ---
[12]
Tilt Stand
Holder
D2 (S-10) ---
[13]
LCD
Module
D2 6(S-11) ---
[14] Speaker (s) D2 4(S-12) ---
[15]
Front
Cabinet
D2 --------------- ---
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
