20070809 13-1 A81N0_01EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
DTV MODULE CBA UNIT
DIGITAL MAIN CBA UNIT
MMA CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
LC195EM82 A
LC195EM87 B
Ref. No. Mark Description Part No.
DTV MODULE CBA UNIT 1ESA14957
Ref. No. Mark Description Part No.
DIGITAL MAIN CBA UNIT 1ESA14798
Ref. No. Mark Description Part No.
A
B
MMA CBA
MMA CBA
Consists of the following:
1ESA14795
1ESA14974
MAIN CBA
FUNCTION CBA
IR SENSOR CBA
JUNCTION CBA
----------
----------
----------
----------
Ref. No. Mark Description Part No.
MAIN CBA
Consists of the following:
----------
CAPACITORS
C22 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C23 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C24 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C25 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C27 FILM CAP.(P) 0.018µF/50V J CA1J183MS029
C28 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V
CHD1JK30B473
C29 CHIP CERAMIC CAP. CH D 5pF/50V CHD1JD3CH5R0
C32 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C34 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C35 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C36 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C37 CHIP CERAMIC CAP. CH J 680pF/50V CHD1JJ3CH681
C39 ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASDLR47
C41 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C42 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C47 CHIP CERAMIC CAP. CH D 8pF/50V CHD1JD3CH8R0
C62 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C63 ELECTROLYTIC CAP. 47µF/50V M CE1JMASDL470
C64 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C67 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C68 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C69 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C70 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C71 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C72 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C74 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C75 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C77 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C80 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C83 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C84 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C85 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C86 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C87 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C89 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C90 ELECTROLYTIC CAP. 10µF/50V M H7 CE1JMASSL100
C91 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C401 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C402 FILM CAP.(P) 0.1µF/50V J CA1J104MS029
C403 CHIP CERAMIC CAP.(1608) B K 5600pF/
50V
CHD1JK30B562
C404 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C405 FILM CAP.(P) 0.1µF/50V J CA1J104MS029
C406 CAP CHIP 5PF 3KV C XC CA3F5R05M016
C407 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C408 CAP CHIP 5PF 3KV C XC CA3F5R05M016
C409 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C410 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C411 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C412 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C413 ELECTROLYTIC CAP. 470µF/25V M CE1EMASDL471
C414 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C415 CAP METALIZED FILM 0.11µF 250V H
MPE
CA2E114DT051
C416 CAP CERAMIC HV 12P 3KV SL J CCD3FJPSL120
C417 CAP CERAMIC HV 12P 3KV SL J CCD3FJPSL120
Ref. No. Mark Description Part No.
To Next Page
