Emerson LC195EM82 User Manual

20070809 12-1 A81N0_01CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
LC195EM82 A
LC195EM87 B
Ref. No. Mark Description Part No.
A1 FRONT CABINET A81N0UH 1EM021786
A3 CONTROL PLATE A81H0UH 1EM322723
A4 REAR CABINET A81N0UH 1EM021787
A6# A RATING LABEL A81N0UH ----------
A6# B RATING LABEL A81N1UH ----------
A7 FUNCTION KNOB A81H0UH 1EM121947
A9 STAND COVER A81N0UH 1EM021788
A10 REAR COVER A7260JH 1EM322484
A11 LED LENS A81N0UH 1EM322707
A12 STAND RUBBER FOOT L5001CB 1EM423855
A13 SENSOR LENS A81N0UH 1EM322708
B2 TILT STAND HOLDER A81N0UH 1EM322710
B3 STAND HOLDER A81N0UH 1EM322709
B6 JACK HOLDER(A) A81N0UH 1EM322705
B7 STAND BASE A81N0UH 1EM322711
B8 STAND HINGE A81N0UH 1EM322729
B9 MODULE PCB HOLDER P7150UT 1EM322373A
CL1901 WIRE ASSEMBLY FFC FFC 40PIN WX1A81N0-01A
CL1902 WIRE ASSEMBLY FFC FFC 40PIN WX1A81N0-01A
CLN801 WIRE ASSEMBLY SPEAKER 2PIN
AWG24
WX1A81N0-05A
CLN802 WIRE ASSEMBLY SPEAKER 2PIN
AWG24
WX1A81N0-05A
L1 SCREW P-TIGHT M3X10 BIND HEAD+ GBJP3100
L2 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L3 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L5 DOUBLE SEMS SCREW M4X9 + BLACK
L0130UA
0EM408146A
L6 DOUBLE SEMS SCREW M4X14 + BLK FPH34140
LCD1 A LCD MODULE 19INCH WIDE CMO
19INCH WXGA
UG190XA
LCD1 B LCD MODULE 19INCH WIDE SVA
19INCH WXGA
UG190XB
SP801 SPEAKER MAGNETIC S0306N01 DSD0806XQ001
SP802 SPEAKER MAGNETIC S0306N01 DSD0806XQ001
PACKING
S1 CARTON A81N0UH 1EM322714
S2 STYROFOAM BOTTOM A81N0UH 1EM021790
S3 STYROFOAM TOP A81N0UH 1EM021789
S4 SET BAG A81N0UH 1EM322872
S5 RFID LABEL P7100UM ----------
S6 STAND BAG A81N0UH 1EM424597
S7 LABEL EAS(H3761UD) MAKER
NO.ZLLFNSLE1
----------
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2# OWNERS MANUAL A81N0UH 1EMN22282
X3 REMOTE CONTROL NF604UD NF604UD
X4 DRY BATTERY(SUNRISE) R6SSE/2S XB0M451MS002
X5 SCREW BAG A81N0UH 1EM424596
Ref. No. Mark Description Part No.

Emerson LC195EM82 Specifications

General

Brand	Emerson
Model	LC195EM82
Category	LCD TV
Language	English
