20070809 13-7 A81N0_01EL
FUNCTION CBA
IR SENSOR CBA
JUNCTION CBA
JK701 Y/C JACK YKF51-5646N JYEJ040JC001
JK702 JACK RCA PCB S AV-4B-70HH JXRJ010SNJ06
JK703 RCA JACK AV-4B-54H YELLOW JXRJ010SNJ01
JK704 RCA JACK WHITE AV-4B-58H WHITE JXRJ010SNJ04
JK705 RCA JACK AV-4A-57H RED JYRJ010SNJ01
JK706 RCA JACK AV-4B-55H JXRJ010SNJ05
JK707 RCA JACK AV-4B-56H JXRJ010SNJ02
JK708 RCA JACK AV-4B-57H JXRJ010SNJ03
JK709 RCA JACK WHITE AV-4B-58H WHITE JXRJ010SNJ04
JK710 RCA JACK AV-4A-57H RED JYRJ010SNJ01
JK801 MINIATURE JACK(PB FREE) CKX-035-
318AZ4
JYSL010SNJ01
JS67 PCB JUMPER D0.6-P7.5 JW7.5T
JS115 PCB JUMPER D0.6-P5.0 JW5.0T
JS116 PCB JUMPER D0.6-P5.0 JW5.0T
JS121 PCB JUMPER D0.6-P5.0 JW5.0T
JS701 PCB JUMPER D0.6-P5.0 JW5.0T
JS902 PCB JUMPER D0.6-P5.0 JW5.0T
L4 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA601# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
SF11 FILTER CERAMIC B
SAFHS45M7VAUM01B05
FBB456LMR006
T401# TRANS INVERTER ETJV26ZE11AC LTZ3PC0MS001
T601# TRANS POWER 7729 LTT2PC0KT026
TP1803 PCB JUMPER D0.6-P5.0 JW5.0T
TU61 TUNER UNIT U4002AF UTUNATSSP001
Ref. No. Mark Description Part No.
FUNCTION CBA
Consists of the following:
----------
CAPACITORS
C1101 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1102 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1103 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
RESISTORS
R1101 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1102 PCB JUMPER D0.6-P5.0 JW5.0T
R1103 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R1104 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1105 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
R1106 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
R1107 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R1108 CHIP RES. 1/10W J 2.7k Ω RRXAJR5Z0272
R1109 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R1110 CHIP RES. 1/10W J 6.8k Ω RRXAJR5Z0682
SWITCHES
SW1102 TACT SWITCH SKQSAB SST0101AL038
SW1103 TACT SWITCH SKQSAB SST0101AL038
SW1104 TACT SWITCH SKQSAB SST0101AL038
SW1105 TACT SWITCH SKQSAB SST0101AL038
SW1106 TACT SWITCH SKQSAB SST0101AL038
SW1107 TACT SWITCH SKQSAB SST0101AL038
SW1113 TACT SWITCH SKQSAB SST0101AL038
MISCELLANEOUS
BC1101 PCB JUMPER D0.6-P5.0 JW5.0T
Ref. No. Mark Description Part No.
Ref. No. Mark Description Part No.
IR SENSOR CBA
Consists of the following:
----------
CAPACITOR
C1151 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
DIODES
D1152 LED 333GT/E NPHZ00333GTE
D1153 LED LTL-4214M1 NPQZLTL4214M
TRANSISTORS
Q1151 NPN TRANSISTOR KRC103M-AT/P NQSZKRC103MP
Q1152 NPN TRANSISTOR KRC103M-AT/P NQSZKRC103MP
RESISTORS
R1151 CARBON RES. 1/4W J 120 Ω RCX4JATZ0121
R1152 CHIP RES. 1/10W J 330 Ω RRXAJR5Z0331
R1153 CHIP RES. 1/10W J 330 Ω RRXAJR5Z0331
R1156 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1157 CHIP RES. 1/10W J 10 Ω RRXAJR5Z0100
MISCELLANEOUS
RS1151 PHOTO LINK MODULE KSM-712TH2E USESJRSKK044
Ref. No. Mark Description Part No.
JUNCTION CBA
Consists of the following:
----------
CONNECTORS
CN1102 242 SERIES CONNECTOR TUC-P04X-
B1 WHT ST
JCTUB04TG002
CN1152 242 SERIES CONNECTOR TUC-P06X-
B1 WHT ST
JCTUB06TG002
