Mentor MP User Guide 111
Issue: 3 www.controltechniques.com
Parameter
Range(
Ú) Default(Ö)
Type
5.01 Armature firing angle 0 to 175.0 ° RO Uni FI NC PT
5.02 Armature voltage {di10, 0.45} ±ARMATURE_VOLTAGE_MAX V RO Bi FI NC PT
5.03 Output power ±POWER_MAX kW RO Bi FI NC PT
5.04 Estimated speed ±SPEED_MAX rpm RO Bi FI NC PT
5.05 Line voltage 0 to 1000V rms AC RO Uni FI NC PT
5.06 Machine armature voltage ±ARMATURE_VOLTAGE_MAX V RO Bi FI NC PT
5.07 Motor rated current {SE07, 0.28} 0 to RATED_CURRENT_MAX A RATED_CURRENT_MAX RW Uni RA US
5.08 Base speed {SE08, 0.29} 0.0 to 10,000.0 rpm 1,000.0 RW Uni US
5.09 Armature rated voltage {SE06, 0.27} 0 to ARMATURE_VOLTAGE_MAX Vdc
For 480V drive: 440 Eur 500 USA
For 575V drive: 630 Eur 630 USA
For 690V drive: 760 Eur 760 USA
RW Uni RA US
5.10 Direct firing angle 0 to 165.0 ° 165.0 RW Uni
5.11 Direct firing angle enable OFF (0) or On (1) OFF (0) RW Bit US
5.12 Autotune {SE13, 0.34} 0 to 3 0 RW Uni NC
5.13 Continuous Back End Stop 0 to 165.0 ° 165.0 RW Uni US
5.14 Armature voltage select OFF (0) or On (1) OFF (0) RW Bit US
5.15 Motor constant 0 to 100.0% 50.0% RW Uni US
5.16 DC contactor OFF (0) or On (1) OFF (0) RW Bit US
5.21 Quadrant 1 Enable
0 to 1
1
RW Uni US
5.22 Quadrant 2 Enable RW Uni US
5.23 Quadrant 3 Enable 0 to QUADRANT_MAX RW Uni US
5.24 Quadrant 4 Enable 0 to QUADRANT_MAX RW Uni RA US
5.25 Disable adaptive control
OFF (0) or On (1)
OFF (0)
RW Bit US
5.26 Continuous auto tune RW Bit US
5.28 Field weakening compensation disable Eur: 0, USA: 1 RW Bit US
5.29 Motor saturation breakpoint 1
0 to 100% of rated flux
50 RW Uni US
5.30 Motor saturation breakpoint 2 75 RW Uni US
5.32 Motor torque per amp
0.000 to 50.000 NmA
-1
RO Uni
5.43 Armature mode 0 to 8 0 RW Txt US
5.44 Bridge request output
0 to 1
RW Bit
5.45
Slave bridge request status
RW Bit
5.46 RW Bit
5.47 RW Bit
5.50 Security unlock 0 to 999 RW Uni NC PT
5.52 IR drop
±ARMATURE_VOLTAGE_MAX Vdc
RO Bi FI NC PT
5.53 Back emf RO Bi FI NC PT
5.54 Flux feedback ±150% RO Bi FI NC PT
5.55 Flux demand ±120% RW Bi FI NC PT
5.56 Field current feedback {di09, 0.44} ±50.00 A RO Bi FI NC PT
5.57 Percentage voltage demand ±150.0% RO Bi FI NC PT
5.58 Field firing angle 0 to 180.0 ° RO Uni FI NC PT
5.59 Back emf set point 0 to ARMATURE_VOLTAGE_MAX Vdc
For 480V Drive: 440 Eur 500 USA
For 575V Drive: 630 Eur 630 USA
For 690V Drive: 760 Eur 760 USA
RW Uni US
5.60 Field output voltage 0 to 500Vdc
RO Uni FI NC PT
5.61 Armature Resistance 0 to 6.0000Ω 0.0000 RW Uni US
5.62 Spill over loop P gain
0 to 300.00
0.40 RW Uni US
5.63 Spill over loop I gain 5.00 RW Uni US
5.64 Field weakening enable
0 to 1
0 RW Bit US
5.65 Enable economy timeout Eur: 0, USA: 1 RW Bit US
5.66 Economy timeout 0 to 255s 30s RW Uni US
5.67 Field economy level 0 to 120.0% 25.0% RW Uni US
5.68 Maximum flux 0 to MAX_FIELD_FLUX % 100.0% RW Uni US
5.69 Minimum flux 0 to 120.0% 50.0% RW Uni US
5.70 Rated field current {SE10, 0.31} 0 to FIELD_CURRENT_SET_MAX
Size 1 - Eur: 2A , USA: 8A
Size 2A & B - Eur: 3A, USA: 20A
Size 2C & D - Eur: 5A, USA: 20A
RW Uni RA PT US
5.71 Flux loop P gain 0 to 30.00 3.00 RW Uni PT US
5.72 Flux loop I gain 0 to 300.00 60.00 RW Uni US
5.73 Rated field voltage {SE11, 0.32} 0 to 500.0 Vdc Eur: 360, USA: 300 RW Uni US
5.74 Rated field compensation factor 0 to 100% 100% RW Uni PT US
5.75 Field voltage mode select 0 to 1 Eur: 0, USA: 1 RW Bit US
5.76 Field controller supply 0 to 550 rms Vac
RO Uni FI NC PT
5.77 Enable field control {SE12, 0.33} 0 to 1 0 RW Bit US
5.78 Field mode 0 to 2 (IntrnL (0), EtrnL (1) and E FULL (2)) IntrnL (0) RW Txt US
5.79 Economy active 0 to 1
RO Bit
5.80 Economy level select OFF (0) or On (1) OFF (0) RW Bit US
5.81 Field thermal time constant 0.0 to 3000.0 24.0 RW Uni US
5.82 Field overload accumulator 0 to 100.0%
RO Uni NC PT
5.83 Field reversal enable 0 to ONLY_2_QUADRANT 0 RW Uni RA US
5.84 Field flux threshold 0 to 100% 75% RW Uni US
5.85 Flux demand invert 0 to 1
RO Bit NC PT
5.86 Speed error invert 0 to 1
RO Bit NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
