Mentor MP User Guide 113
Issue: 3 www.controltechniques.com
Parameter
Range(
Ú) Default(Ö)
Type
6.01 Stop mode 0 to 2 1 RW Uni US
6.03 Main loss ride through OFF (0) or On (1) OFF (0) RW Bit US
6.04 Start/stop logic select 0 to 4 4 RW Uni US
6.08 Hold zero speed OFF (0) or On (1) OFF (0) RW Bit US
6.09 Catch a spinning motor 0 to 1 1 RW Uni US
6.12 Enable stop key OFF (0) or On (1) OFF (0) RW Bit US
6.13 Enable forward/reverse key 0 to 2 0 RW Uni US
6.15 Drive enable OFF (0) or On (1) On (1) RW Bit US
6.16 Electricity cost per kWh 0.0 to 600.0 currency units per kWh 0.0 RW Uni US
6.17 Reset energy meter OFF (0) or On (1) OFF (0) RW Bit NC
6.18 Time between filter changes 0 to 30,000 hrs 0 RW Uni US
6.19 Filter change required / change done OFF (0) or On (1) OFF (0) RW Bit PT
6.20 Powered-up time: years.days 0 to 9.364 Years.Days
RW Uni NC PT
6.21 Powered-up time: hours.minutes 0 to 23.59 Hours.Minutes RW Uni NC PT
6.22 Run time: years.days 0 to 9.364 Years.Days RO Uni NC PT PS
6.23 Run time: hours.minutes 0 to 23.59 Hours.Minutes RO Uni NC PT PS
6.24 Energy meter: MWh ±9999 MWh RO Bi NC PT PS
6.25 Energy meter: kWh ±999 kWh RO Bi NC PT PS
6.26 Running cost ±32000 RO Bi FI NC PT
6.27 Time before filter change due 0 to 30,000 hrs RO Uni NC PT PS
6.28 Select clock for trip log time stamping
OFF (0) or On (1)
OFF (0) RW Bit US
6.29 Hardware enable
RO Bit NC PT
6.30 Sequencing bit: Run forward
OFF (0)
RW Bit NC
6.31 Sequencing bit: Jog RW Bit NC
6.32
Sequencing bit: Run/reverse
RW Bit NC
6.33 Sequencing bit: Forward/reverse RW Bit NC
6.34 Sequencing bit: Run RW Bit NC
6.35 Forward limit switch RW Bit NC
6.36 Reverse limit switch RW Bit NC
6.37 Sequencing bit: Jog reverse RW Bit NC
6.39 Sequencing bit: Not stop RW Bit NC
6.40 Enable sequencer latching RW Bit US
6.41 Drive event flags 0 to 65535 0 RW Uni NC
6.42 Control word 0 to 32767 0 RW Uni NC
6.43 Control word enable
OFF (0) or On (1)
OFF (0) RW Bit US
6.45 Force cooling fan to run at full speed
RW Bit US
6.49
Disable multi-module drive module
number storing on trip
OFF (0) or On (1) OFF (0) RW Bit US
6.50 Drive comms state 0 to 3
RO Txt NC PT
6.52 Zero reference interlock OFF (0) or On (1) OFF (0) RW Bit US
6.54 Run rising edge delay 0 to 25.0s 0.3 RW Uni US
6.55 Contactor active OFF (0) or On (1)
RO Bit NC PT
6.56 Drive active falling edge delay 0 to 255s 0s RW Uni US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
