Mentor MP User Guide 115
Issue: 3 www.controltechniques.com
Parameter
Range(
Ú) Default(Ö)
Type
7.01 Analog input 1 {in02, 0.82} ±100.00% RO Bi NC PT
7.02 Analog input 2 {in03, 0.83}
±100.0%
RO Bi NC PT
7.03 Analog input 3 {in04, 0.84} RO Bi NC PT
7.04 Power circuit temperature -128°C to 127°C RO Bi NC PT
7.08 Analog input 1 scaling 0 to 40.000 1.000 RW Uni US
7.09 Analog input 1 invert OFF (0) to On (1) OFF (0) RW Bit US
7.10 Analog input 1 destination Pr 0.00 to 22.99 Pr 1.36 RW Uni PT US
7.11 Analog input 2 mode 0 to 6 6 RW Uni US
7.12 Analog input 2 scaling 0 to 40.000 1.000 RW Uni US
7.13 Analog input 2 invert OFF (0) to On (1) OFF (0) RW Bit US
7.14 Analog input 2 destination Pr 0.00 to 22.99 Pr 1.37 RW Uni PT US
7.15 Analog input 3 mode {in01, 0.81} 0 to 9 Eur: 8, USA: 6 RW Txt US
7.16 Analog input 3 scaling 0 to 40.000 1.000 RW Uni US
7.17 Analog input 3 invert OFF (0) to On (1) OFF (0) RW Bit US
7.18 Analog input 3 destination
Pr 0.00 to 22.99
Pr 0.00 RW Uni PT US
7.19 Analog output 1 source Pr 3.02 RW Uni PT US
7.20 Analog output 1 scaling 0.000 to 40.000 1.000 RW Uni US
7.21 Analog output 1 mode 0 to 3 0 RW Txt US
7.22 Analog output 2 source Pr 0.00 to 22.99 Pr 4.02 RW Uni PT US
7.23 Analog output 2 scaling 0.000 to 40.000 1.000 RW Uni US
7.24 Analog output 2 mode
0 to 3 0RWTxtUS
7.28 Analog input current loop loss 2
OFF (0) to On (1)
RO Bit NC PT
7.29 Analog input current loop loss 3 RO Bit NC PT
7.30 Analog input 1 offset ±100.00% 0.00 RW Bi US
7.31 Analog input 2 offset
±100.0% 0.0
RW Bi US
7.32 Analog input 3 offset RW Bi US
7.34 SCR / Thyristor junction temperature 0 to 150°C
RO Uni NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
