Emerson NetSure 721NPBB User Manual

NetSure
™
-48V DC Power System
User Instructions, UM582127000 (Issue AD, January 20, 2014)
Spec. No: 582127000 Code: UM582127000
Model No: 721NPBB Issue AD, January 20, 2014
[17]
Figure 11. ACU+ CAN Bus, Module Mounting Shelf Spec. No. 588705300
Distribution
Cabinet Wire
Harness
Brown and
Brown/White
Wires
Slate and
Slate/White Wires
Exploded View Shown to
Illustrate Wire Connections Only
Existing Module
Mounting Shelf
Existing Module
Mounting Shelf
These connectors
are factory connected.
These connectors
are factory connected.
These connectors
are factory connected.
Existing Module
Mounting Shelf
Expansion Modul
e
Mounting Shelf
D
isconnect cable coming
f
rom distribution cabinet
f
rom this connector on
b
ottom-most existing
s
helf, then connect to the
s
ame connector on the
e
xpansion shelf.
Now connect these
two connectors together.
Rear View
Factory provided jumper
to bring connectors to
same side of shelf.
Rear View
Factory provided jumper
to bring connectors to
same side of shelf.
Rear View
Factory provided jumper
to bring connectors to
same side of shelf.
Rear View
Factory provided jumper
to bring connectors to
same side of shelf.
X
