Emerson PNC001-A Series Important Product Information

GFK-2573AD May 2023
16
Subject
Feature
Minimum Version Required
RX3i PNC001 Release 2.00
(or later)
Non-Hot Standby
Redundancy system
PAC Machine Edition 7.00 SIM 8
PNC001-Bxxx and PNC001-Ax Hardware
Comparison
This section outlines the differences between the new (-Bxxx) and old (-Ax) hardware implementations.
Functionally, the two are equivalent, except for the removal of the micro USB port and the Command
Language Interface (CLI) which operated via that port.
Topic
-Ax
-Bxxx
Appearance
Refer to Figure 2, GFK-2571K
Refer to Figure 3, GFK-2571K
Case
Plastic
Metal
Attachment to Rack
Via plastic case latch and heatsink screw
Via two Phillip’s head machine screws
Heatsink
Remove a plastic knockout from the rack
No knockout removal required
Status LEDs
6 LEDs
5 LEDs (no USB LED)
LED Behavior
Refer to Section 2.8, GFK-2571K
Refer to Section 2.8, GFK-2571K
Ethernet Port LEDs
4 singleton LEDs (top of the faceplate)
4 banks of LEDs (bottom of the
faceplate).
The digits representing the port numbers
are backlit by LEDs.
µUSB Port
Present
Absent
Command Line
Interface
Uses µUSB Port
Not available
RJ45 Connector on
Faceplate
Absent
Present (Disabled)
Power Requirements
Higher
Lower
Operating Temperature
Range
0°C to 60°C
-25°C to 60°C
Module Reset
Pushbutton “Restart”
Membrane “Reset”
