If using PROFINET System
Redundancy, users MUST
upgrade the PNC001
(PROFINET Controller) to
Version 2.2 or later
firmware.
Effective with PME 8.6 SIM 3 and PME 8.5 SIM 11 (PPS 2.6
SIM3 and PPS 2.5 SIM11), the PNC001 is configured to use
RT Class 2 for redundant PROFINET connections. To meet
specifications, this requires PNC001 firmware 2.2 or later.
Under these conditions, redundant VersaMax and/or
CEP PROFINET I/O will NOT connect or transfer I/O or
Alarm Data if the PNC001 is running firmware prior to
Version 2.2.
RX3i PROFINET
Scanner Version
Requirements
Single fiber break
detection
IC695PNS001-Bxxx or IC695PNS101
Release 3.40
IC695CMM002/004
support in IC695PNS001-
Bxxx, IC695PNS001, and
IC695CEP001
IC695PNS001 Bxxx or IC695PNS101 with firmware version
3.35 or later and GSDML version: GSDML V2.3
IntelligentPlatformsLLC RX3iPNS-20210817.xml
RX3i PNC001 Release 3.00
New HW/FW to address
component obsolescence
IC695PNS001 with firmware version 3.00 or later and
GSDML version: GSDML-V2.3-GEIP-RX3iPNS-20170109.xml.
RX3i PNC001 Release 2.26
Support Remote Get
Device Information
COMMREQ
IC695PNS001 with firmware version 2.41 or later and
GSDML version: GSDML-V2.3-GEIP-RX3iPNS-20160602.xml.
Programmer version
requirements
IC695CMM002/004
support in IC695PNS001-
Bxxx, IC695PNS001, and
IC695CEP001
PME 8.50 SIM 9 or 8.60 SIM 1
RX3i PNC001 Release
2.11(or later)
128 PROFINET Device
Support
4
Critical Network Port
4
PME 8.50 SIM 9 or 8.60 SIM 1
RX3i PNC001 Release 2.00
(or later)
Hot Standby Redundancy
with PROFINET I/O
Non-Hot Standby
Redundancy system using
CRU320
PAC Machine Edition 8.00 SIM 5
Attempts to store a configuration utilizing this feature to a prior-release PNC001 will result in an Unable to deliver configuration to module
fault, which leaves the PNC001 in an un-configured state.
