â–ª Added instructions for replacing the RX3i CPE305/CPE310 real-time clock battery:
Section 2:.
â–ª Corrected definitions of reverse acting and direct acting modes for PID functions:
refer to PACSystems RX7i and RX3i CPU Programmer’s Reference Manual,
GFK-2950 Section 7.
▪ Expanded data for Boolean execution measurements – Appendix A:
â–ª Re-instated instruction times for RX7i CPE030/CRE030/CPE040 release 6.0 as
published in version Q of the manual (unintentionally omitted from version R) –
Appendix A:
â–ª Compatibility information for volatile memory backup batteries has been
consolidated in the PACSystems Battery and Energy Pack Manual, GFK-2741 –
throughout
1.2 PACSystems Control System Overview
The PACSystems controller environment combines performance, productivity, openness
and flexibility. The PACSystems control system integrates advanced technology with
existing systems. The result is seamless migration that protects your investment in I/O
and application development.
1.2.1 Programming and Configuration
PAC Machine Edition programming software provides a universal engineering
development environment for all programming, configuration and diagnostics of
PACSystems. A PACSystems CPU is programmed and configured using the programming
software to perform process and discrete automation for various applications. The CPU
communicates with I/O and smart option modules through a rack-mounted backplane. It
communicates with the programmer and/or HMI devices via the Ethernet ports or via the
serial ports COM1 and COM2 using Serial I/O, or Modbus RTU slave protocols.
1.2.2 Process Systems
PACSystems CPUs with firmware version 5.0 and later support PACProcess Systems (PPS).
PPS is a complete, tightly integrated, seamless process control system using PACSystems,
PACHMI/SCADA, and PACProduction Management Software to provide control,
optimization, and performance management to manage and monitor batch or
continuous manufacturing. It delivers the tools required to design, implement,
document, and maintain an automated process. For information about purchasing PPS
software, refer to the Support website.
