PACSystems™ RX3i and RSTi-EP CPU Reference Manual Section 1
GFK-2222AK October 2019
Introduction 8
▪ Effective with CPE310/CPE305 firmware version 8.20, or CPE330 firmware version
8.45, the CPE embedded Ethernet port supports OPC UA Server. This feature is
available on all firmware versions of CPE400 and CPL410. Refer to PACSystems RX3i
TCP/IP Ethernet Communications User Manual, GFK-2224 version M or higher (Section
10).
▪ Effective with RX3i firmware version 8.30
3
, the CPE310/CPE305 CPUs also support
Ethernet Global Data (EGD). Prior to that firmware version, EGD was only available in
the RX3i via the RX3i Ethernet Interface Module (IC695ETM001). With this upgrade,
these CPUs are positioned as a direct replacement for S90-30 IC693CPU374.
▪ Effective with RX3i firmware version 8.60
4
, the CPE330 supports Ethernet Global
Data (EGD) Class 1. This feature is available on all firmware versions of CPE400
5
,
CPL410
6
and CPE302
11
.
▪ The rack-based IC695ETM001 Ethernet Interface has dual RJ45 ports connected
through an auto-sensing switch. This eliminates the need for rack-to-rack switches
or hubs. The ETM001 supports upload, download and online monitoring, and
provides 32 SRTP channels with a maximum of 48 simultaneous SRTP server
connections. It also supports Modbus TCP. For details on Ethernet Interface
capabilities, refer to PACSystems RX3i TCP/IP Ethernet Communications User Manual,
GFK-2224.
▪ PROFIBUS communications via the PROFIBUS Master module, IC695PBM300. For
details, refer to the PACSystems RX3i PROFIBUS Modules User’s Manual, GFK-2301.
▪ PROFINET communications via any supported PROFINET Controller and any
supported PROFINET Scanner.
▪ Supported PROFINET Controllers include the embedded PROFINET Controller
function offered by IC695CPE400 and IC695CPE330, and the rack-mounted
PROFINET Controller module IC695PNC001.
▪ Supported PROFINET Scanners include the RX3i PROFINET Scanner modules
IC695PNS001
7
, IC695PNS101, the RX3i IC695CEP001, and the VersaMax PROFINET
Scanner modules IC200PNS001 and IC200PNS002.
▪ For details, refer to the PACSystems RX3i PROFINET IO-Controller Manual, GFK-
2571F or later and PACSystems RX3i PROFINET Scanner Manual, GFK-2737F or later.
▪ Effective with the release of IC695CEP001 and IC694CEE001, the RX3i may be
configured to control a remote drop consisting of one or two I/O modules. The RX3i
interface to the remote drop is managed by the PROFINET Controller, IC695PNC001.
3
PAC Machine Edition Release 8.50 SIM 7 is required for EGD Class 1 on Embedded Ethernet interface of CPE305/CPE310.
4
PAC Machine Edition Release 8.60 SIM 5 is required for EGD Class 1 on both LAN1 and LAN2 of CPE330. This PME version also supports
Advanced Configuration Parameters for EGD on CPE330. Alternately, PME Release 8.60 (not SIM 5) supports EGD on CPE330 LAN1 only, and
does not support Advanced Configuration Parameters for EGD.
5
PAC Machine Edition Release 9.00 SIM 8 or later is required for native configuration support of the CPE400.
6
PAC Machine Edition Release 9.50 SIM 10 or later is required for native configuration support of the CPL410.
7
IC695PNS001 firmware version 2.40 added support for a number of I/O modules not previously supported, as documented in PACSystems RX3i
PROFINET Scanner Important Product Information, GFK-2738L.
