Figure 2-2: Roxar Mechanical Retrieval Tool (left) and Roxar Service Valve (right)
The service valve can also be delivered as a single isolation version. The procedures for
operation and maintenance are similar to those for the double isolation valve. For more
information about the single isolation valve, refer to the Roxar Service Valve - Product Data
Sheet.
2.2 Mechanical retriever tool
The Roxar Mechanical Retrieval Tool is based on a telescopic, pressure-balanced design.
This means that when a retrieval tool and service valve are installed on the access fitting,
the tool can be easily operated and telescoped freely, even if it is exposed to pipe pressure.
Figure 2-3: Roxar Mechanical Retrievable Tool
