A Spare parts list
The parts presented in this section are available as spare parts for the mechanical retrieval
tool and service valve.
Note
Some of the parts come in different materials (like seal kits), which need to be verified
against the existing parts before anything is replaced. Other parts, including repair and re-
certification of the tool, are available on request. Contact Emerson for more information.
Mechanical Retrieval Tool
Table A-1: Spare part list for the Mechanical Retrieval Tool
Description Material Part Number Comments
Pressure gauge,
10,000 psi (650 bar)
316L ROX000265295 Position 29 of Roxar
Mechanical Retriever
Assembly
Needle valve
(bleed off valve)
10,153 psi (700 bar)
316L ROX000265307 Position 3 of Roxar Mechanical
Retriever Assembly
Seal kit
for
Mechanical
Retriever
VITON 75 ROX000296784 Kit includes positions 9, 10,
11, 18, 19, and 20 of Roxar
Mechanical Retriever
Assembly
FR 25/90 ROX000314761
ELAST-O-LION 101 ROX000314762
Hammer nut
repair kit
VITON 75 ROX000322232 Kit includes positions 8, 12,
18, 19, and 28 of Roxar
Mechanical Retriever
Assembly
FR 25/90 ROX000322237
ELAST-O-LION 101 ROX000322239
Double ball service valve
Table A-2: Spare part list for the Service Valve
Description Material Part Number Comments
Bleed off valve 316 ROX000303720 Position 17 of Double ball service valve
assembly.
Seal kit
for the double
service valve
VITON 75 ROX000316208 Kit includes positions 1, 2, 7, 8, 11, 12,
13, 14, 15, 16, 19, 20, 31, 34, and 38 of
Double ball service valve assembly
FR 25/90 ROX000316209
ELAST-O-LION
101
ROX000316210
Repair kit
for double
service valve
ROX000321558 Kit includes positions 1, 2, 9, 22, 24, 30,
and 36 of Double ball service valve
assembly
User Manual Spare parts list
ROX000295904 June 2020
www.Emerson.com/Roxar 41
