Emerson Tartarini M Series User Manual

Type M
6
4 x DN
SS Pipe
ø 6 mm
6 x DN
1/4” Connection
4 x DN
6 x DN
SS Pipe
ø 15 mm
SS Pipe
ø 6 mm
1/4” Connection
1/2” Connection
6 x DN
4 x DN
SS Pipe
ø 6 mm
Monitor Regulator
SS Pipe
ø 15 mm
SS Pipe
ø 10 mm
REGULATOR TYPE MBN DN 25 TO DN 65 WITH INTERNAL IMPULSE CONNECTION
REGULATOR TYPE MBN DN 80 TO DN 100 WITH EXTERNAL IMPULSE CONNECTION
MONITOR TYPE MBF-M AND REGULATOR TYPE MN WITH EXTERNAL IMPULSE CONNECTIONS
Figure 6. Connection Schematics
INSTALLATION
