Page #23 background imageLoading...
Page #23 background image
Figure 6-13: Direct Mount Wiring Diagram for 4-Wire Active Device
with No 4-20 mA Loop
Green
Yellow
White
Black
Red
A
B
C
COMM +
COMM -
Power -
Power +
D
E
A. THUM Adapter
B. Wired device
C. Ground
D. Splice connector
E. Load resistor ≥ 250 Ω
September 2020 Quick Start Guide
Quick Start Guide 23
